Compression Testers #1353903

Box Compression Tester made of a set of plates one is attached to the load measuring arrangement and the other is movable plate which is move with the help of motor, gearbox, and screw and nut arrangement, the movable plate have the facility of over travel and under travel. The load measuring arrangement is digital type. The box of which the compression strength is to be determined is placed on the lower plate, due to the motion of the movable plate the box is compressed and the compression load is directly read out on the digital indicator on the panel. The deflection of the box also measured with the help of the digital deflection indicator.

The instrument is made in two parts, one is for main instrument and the other is the control panel. The ultimate test is to determining overall quality and performance of the container. The instrument is bright chrome plating, zinc plating, painted in metallic paints. It is supplied complied with electrical which include micro-switches, Push buttons and contactors for safe and convenient operation.

The compressibility of rubberized cork composition sheets is determined by finding the percentage reduction in thickness of a test specimen taken from the sheet under test under a small initial load and a large final load. The percentage recovery is determined by finding the ratio between the recovery in thickness after removal of final load and the reduction in thickness under the final load, the thickness in unloaded state being measured with only the small initial load acting on the test specimen.

 The Compressibility and Recovery Tester for rubberized cork composition sheets consists of an anvil, an indenter which can be moved vertically inside a guide bush to apply the initial load on the test specimen kept on the anvil, and a lever arrangement to apply the specified final load on the test specimen.

 The indenter is made from steel and has a diameter of 25 mm. It also serves to apply the initial load. A dial gauge indicator is provided to measure the thickness of the test specimen at the center of the indenter.

 The major load is applied with the help of a spring dynamometer acting through a lever mechanism. The spring dynamometer is moved up with the help of screw arrangement. This movement causes the load on the lever to get transmitted to the test specimen through the indenter.

 The various components of the equipment are mounted on a sturdy fabricated steel base plate. The equipment is finished in dark shore blue metallic painting and bright chrome plating to give it a corrosion resistant finish.

RELATED STANDARDS

 IS 4253 (p 2) - 1980              :  Specification for cork composition Sheets

Compression set tests is intended to measure the ability of rubber compounds to retain elastic properties after prolonged action of a known compressive stress under static loading.
