Seetharam Mechatronics Private Limited Chennai, Tamil Nadu

KOAL Touch series is designed specifically to work with Strain sensors / Analog input / Encoders / LVDT. The setup sequence is simple and quick. It supports fast and high resolution measurements. The 2.8 inch resistive touch screen display is an impressive and user friendly interface for navigating the settings and menus. KOAL Touch can be used as Indicator Controllers for Industrial Press, Testing Machine, and SPMs etc. Features 1)TFT 320 X 240 (2.8”) Resistive touch screen multi-colour display. 2)Ÿ Easy to understand; User friendly special icons; Password protection for settings, 3)Ÿ User configurable input sampling and display update speed 4)Nonvolatile memory retains all programmable parameters and display values. 5) RS232 and RS 485 communication port for PC interface. 6)Remote Peak & Tare option; Engineering unit selections. 7) Soft Calibration by sensor rated value or actual / field load.

• Brand NameSEETHARAM
• MaterialStainless Steel
• ColorGolden Orange
• Automation GradeSemi Automatic
• ApplicationIndustrial Use
• TypeLoad Cell
• Output5mv
• Rated Load5 Ton
• Country of OriginIndia
• TheoryModel FCIT Load Cells Have Female Thread Mounting And Measure Both Tension & Compression Load Force.

• Brand NameSEETHARAM
• ColorWhite
• NameUNIPOT
• Country of OriginIndia

The GAMAN series linear displacement pulsed probe is a spring loaded plunger type precision linear measurement sensor. Standard stroke length ranges are 25 and 50mm. It is a machined aluminum enclosure with smooth linear bearings for repeatable measurements. They have a wide range of applications in Production, Metrology, Multipoint Inspection Stations, Thickness / Stroke measuring equipment devices. The in-built electronics support interface with low cost PLCs, thus making precision measurement a low cost solution. Stand-alone indicators are also available as display for this sensor. FEATURES 1. Standard 10mm diameter mounting stem 2. Compact design 3. Linear ranges from 25mm to 50mm 4. 12μm resolution (option 3 & 5μm) 5. 5 Pin circular locking connector 6. RS485 communication output

• MaterialPlastic
• ColorBlack
• ConditionNew
• ApplicationIndustrial Use
• TypeHumidity Sensors
• Country of OriginIndia

Features Model RTDS torque sensor measures the torque of continuous rotating object. High Integrity Contact material connector provides long term signal stability and high accuracy. These models are most appropriate for industrial measurement. Applications include the performance testers for automotive components such as clutch, transmissions, motors and pumps. Option: Foot mount.
