YSU-617A Fully Automatic Table Top Flash Autoclave

Listing ID #7473319

Required Process Control and Other Features:

1.      AUTOMATIC CONTROL SYSTEM:

The Machine is equipped with fully automatic control system. Having each function (7+) of autoclave automated such as:

a)       Auto Pre Vacuum Pulsing

b)      Auto Ster

c)       Auto Exhaust

d)      Auto Vacuum Dry

e)      Auto Filter Air Dry

f)       Auto Fault Detection & Notification System

g)      Auto Shutdown

2.       PRE-PROGAMMED CYCLES:

The sterilizer has equipped 5 pre-programmed cycles as mentioned below:

a) Liquid Cycle

b) Packs Cycle

c) Flexible Cycle

d) Wrapped Cycle

e) Unwrapped Cycle

3.       USER CUSTOMIZABLE CYCLE:

The machine having user variable cycle will allow user to customize the temperature settings, pressure settings and vacuum pulse settings.

4.       PASSWORD PROTECTION:

a) The sterilizer settings are password protected.

b) The date and time settings are password protected, and User is able to update date and time settings on the screen for better record keeping.

5.       OPTIONAL PRINTING FACILITY:

a) The user is record the progress of the sterilization cycle in real time therefore online real time printing facility will be provided.

b) The user can print the following details:

Date and time of the cycle.

Status of the cycle.

Temperature at drain and chamber pressure at every event change and during sterile hold it can be printed at desired interval, minimum of 1 minute.

All undesired situation (faults) are to be printed at the time of fault generation.

Note:- Printer will be provided at extra cost with this model.

6.       OPTIONAL CYCLE DATA STORAGE FACILITY:

Historical cycle data gets stored in the memory of sterilizer which can be easily retrieved at will through USB.

Note:- Optional cycle data storage facility will be provided at extra cost with this model.

7.       STATE OF THE ART – VACUUM SYSTEM:

Heavy Duty Branded- Oil free diaphragm type vacuum pump is provided to remove the air/gas from the chamber.

8.       DOOR:

The Sterilizer has manual sliding single door.

Door frame is strong & robust enough to ensure smooth door movement & consistency in alignment.

Door movement is smooth to ensure proper door alignment over a long period of time.

9.       QUICK HOT AIR DRYING SYSTEM:

Specially designed drying valves have been provided to ensure each load comes out completely dry.

11.     AUTOMATIC TEMPERATURE DETECTION SYSTEM:

The machine is equipped with temperature detection system and the user will be notified in case the machine fails to reach the set temperature or if the temperature over shoots.

12.     AUTOMATIC LOW WATER CUT OFF SYSTEM:

The machine is equipped with automatic low water cut-off system. When the water level decreases below a threshold then heating elements will automatically turn off. The user will be notified in case the water level is not optimum for regular machine operation.

13.     AUTOMATIC PRESSURE CONTROL SYSTEM:

The sterilizer has automatic pressure control switch which automatically maintain the desired pressure and restricts any abnormal/ unsafe rise of pressure in the sterilizer.

14.     AIRTIGHT SEALING:

Heavy duty branded silicon gasket will be provided for airtight seal.

15.     SOLENOID VALVE:

The sterilizer is equipped with branded solenoid valves for automatic process.

16.     ANALOGUE GAUGES:

a) The Sterilizer is fitted with branded NABH calibrated analogue chamber pressure (Compound) gauge to measure the pressure and vacuum of chamber.

b) The Sterilizer is fitted with branded NABH calibrated analogue jacket pressure gauge to measure the jacket & boiler pressure.

17.     EUROPEAN STYLE OUTER COVER:

The sterilizer has fully covered design with panelling back and both the sides RHS & LHS.

18.     SAFETY FEATURES:

18.1   AUTOMATIC FAULT DETECTION AND ALARM SYSTEM:

The Machine is equipped with precision sensors capable of detecting various faults and notifying the user thereby making this a smart sterilizer:

a) AUTOMATIC DUAL DOOR LOCK AND DETECTION SYSTEM: It is an inbuilt feature where In case the doors are not closed properly the sterilizer prevents the user from starting the cycle and visually notifies the same

b) TEMPERATURE DETECTION SYSTEM: The user is notified in case the machine fails to reach the set temperature or if the temperature overshoots

c) AUTOMATIC PRESSURE DETECTION AND MAINTENANCE: Chamber & Jacket pressure is maintained automatically. In case the pressure fails to reach the set value or if it drops the user is notified

d) WATER DETECTION SYSTEM: The user will be notified in case the water level is not optimum for regular machine operation.

e) AUTOMATIC ELECTRICITY ECONOMIZER: Once the temperature is reached or water level is not at optimum level the sterilizer will automatically cut off the heater system to save electricity.

f)      VACUUM LOCK DETECTION SYSTEM: this system detects the total vacuum generated and total time of vacuum maintained in chamber. It is also capable of detecting steam and air leakage.

g)     POWER CUT CYCLE RETENTION AND MANAGEMENT SYSTEM: the machine is equipped to deal with any power outages and based on the duration of the power outage the user is notified.

18.2   EMERGENCY STOP:

An Easily Accessible emergency stop is provided on main control panel door.

18.3  POWER FAILURE:

Equipment settings will not get disturbed due to power failure and will not restart without human intervention.

18.4   FAILURE MODE DETECTION:

Equipment indicate fault through audio / visual signal with details on control panel/PLC (Failure mode detection).

18.5   HYDRAULIC  TESTING:

Complete sterilizer including chamber and piping are hydraulically tested at 2 times the working pressure.

18.6   INSULATION:

The sterilizer is completely insulated to prevent any burns caused due to accidental contact to sterilizer body.
