YSU-404 Bronze Vertical Cylindrical High Pressure Steam Sterilizer

Listing ID #7473735

Process Control and Other Features:

1.   STAINLESS STEEL 304 TRIPLE WALLED CONSTRUCTIONS:

• a) Triple walled design with mineral wool insulation for prevention of burn to users.
• b) Top quality stainless steel 304/316 construction including piping to avoid corrosion and contamination of.

2.       Quick Hot Air Drying System:

• Specially Designed Drying Valves Have Been Provided to Ensure Each Load Comes Out Completely Dry.

3.     State of the Art – Vacuum System:

• Vacuum Is a Must for Optimum Steam Penetration & Drying of Sterilization Load. Our “Steri” Vertical Steam Sterilizer Is Equipped with Cutting Edge Vacuum Which Sets Us Apart from Our Competition.

4.     Automatic Low Water Cut Off System:

• The Machine Is Equipped with Water Detection System. When the Water Level Decreases Below a Threshold Then Heating Elements Will Automatically Turn Off. the User Will Be Notified in Case the Water Level Is Not Optimum for Regular Machine Operation.

5.     Automatic Pressure Control System:

The Sterilizer Has Automatic Pressure Control Switch Which Automatically Maintain the Desired Pressure and Restricts Any Abnormal/ Unsafe Rise of Pressure in the Sterilizer.

6.     Validation Port:

• The Sterilizer Is Equipped with External Validation Port for the Sterilizer Calibration.

7.     Water Level Indicator:

• The Sterilizer Is Equipped with Water Level Gauge Glass to Indicate the Water Level.

8.     Airtight Sealing:

• Heavy Duty Branded Silicon Gasket Will Be Provided for Airtight Seal.

9.     Analogue Gauges:

• A) The Sterilizer Is Fitted with Branded Nabh Calibrated Analogue Chamber Pressure (Compound) Gauge to Measure the Pressure and Vacuum of Chamber.
• B) The Sterilizer Is Fitted with Branded Nabh Calibrated Analogue Jacket Pressure Gauge to Measure the Jacket & Boiler Pressure.
• C) The Sterilizer Is Fitted with Branded Nabh Calibrated Analogue Chamber Temperature Gauge to Measure and Indicate Temperature.

10.   Safety Features:

10.1 Automatic Shut Off Valve:

• Prevents Hazardous Leakage of Hot Steam and Boiled Water Due to Breakage of Glass Tube.

10.2 Hydraulic  Testing:

• Complete Sterilizer Including Chamber, Jacket, and Piping Are Hydraulically Tested at 2 Times the Working Pressure.

10.3 Vacuum Breaker:

• The Sterilizer Is Fitted with Vacuum Breaker System to Prevent Collapsing of Jacket Due to Vacuum Formed by Condensation of Steam.

10.4 Safety Valve:

• The Sterilizer Is Fitted with a Safety Valve.

10.5 Insulation:

• The Sterilizer Is Completely Insulated to Prevent Any Burns Caused Due to Accidental Contact to Sterilizer Body.
