X Ray Door

Listing ID #3952049

Get Latest Price

Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Product Details

We are engaged in offering a wide range of X-ray Door installed with high density leaded doors that prevent the electromagnetic radiations to escape and change into ionizing radiations. The optimum lead thickness is designed for maximum body protection. These have mechanically interlocked vertical edges for added strength and rigidity.

Purpose of door
The high density leaded doors are being designed in such a manner that the electromagnetic radiations escaping through the door are contained and prevented from ionizing radiations. Understanding the nature of shielding effect, optimum thickness of lead shield is used in door design for maximum human body protection.

Features

45mm general purpose full flush design, rated for light to extra heavy-duty use
Thick lead shield of 1mm, 2mm or 3mm core provides structural strength and
block to reduce electromagnetic wave effect.
Full-coat internal contact adhesive for permanent pressure
bond and rust prevention

Mechanically interlocked vertical edges for added strength and rigidity
Electro statically applied prime base coat / PU painted
Factory made insulated glazing

Standard Specifications

1.2mm thick, Galvanized Iron/ SS304 Hairline finish, 100x75 mm Single Rebated Frame / 150x75 Double Rebated Frames
0.8mm thick, Galvanized Iron / SS304 Hairline finish, 45mm thick Shutters
4mm thick steel Back up plates for accessories mounting
Color as per RAL standards

Options

Glazing – Single or Double Glazed

Radiation Shield

for X- Ray / Cath Labs

Electro Magnetic Lock for Access Controls

Accessories :
Standard

Hinges- SS 304
Pivots – Aluminum Die Casted
Locks – Concealed with SS 304 Sash Bar & 70mm Euro Profile Cylinder both side keys.
Push Plates – SS 304
Kick Plates – SS 304
Tower Bolt - Concealed
Door Closer – External Std. Arm
Sliding Door Kit

Optional

Vision Panel-lead glass
Drop Seal ( Automatic Door bottom)
Panic Bar
Locks- External , Concealed Dead Bolt
Cylinder with Key and thumb turn
Tower Bolt - External
Door Closer –Hold Open Arm, Floor Spring
Door Coordinators for Sequencing Double Door
High Impact Crash Guards
Key hole with auxillary lid having lead shield
