Vials Sticker Labeler Machine, Power : 2.5 Amp.

Listing ID #3828088

  • Power2.5 Amp.
  • SpeedUp to 300 Labels per minute depending on Product and Label Size
  • Pneumatic cylindersSMC / Festo make
  • Label Roll Dia.400 mm
  • Supply Type Exporter, Supplier
  • Preferred Buyer Location All over the world
View More Details
Send Enquiry

Company Information

  • Member Since 9 Years
  • Nature of Business Manufacturer
  • GST No. 24AANCS9768F1ZQ

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

  • Power 2.5 Amp.
  • All Electrical / Electronic cables Labb – Germany make
  • Sensors ( Product / Label ) Leuze – USA or Sick Germany make
  • PLC Programmable Logic Controller Unit – DELTA Make
  • Gap Between two Labels Appx. 3 mm
  • Touch Screen Delta Make Touch screen
  • Label Height 8 mm to 50/70/90 mm Standard*
  • Pneumatic cylinders SMC / Festo make
  • AC Drive ( Variable Speed) Delta Make
  • Servo Motor Panasonic / Delta Make
  • Electrical 220 VAC Single Phase Power Supply (50/60 Hz)
  • Microprocessor Microprocessor controller by Multipack make
  • Labelling accuracy ±1mm
  • Label Length 12 mm Minimum
  • Capacity 0.75 Kw
  • Speed Up to 300 Labels per minute depending on Product and Label Size
  • Core Dia. 75/76 mm
  • Product Diameter Up to 25 mm*
  • Stepper Motor Sanyo denki stepper motor – Japan make
  • Label Roll Dia. 400 mm
  • Product Feeding Hopper height 850 mm*

This sticker labeling machine is utilized for labeling round ampoules, vials, and many other round shaped objects. Hence it is also referred as ampoule labeling machine. It is very sturdy, highly user friendly and virtually maintenance free. This SBRSL-300 model also includes an advanced micro processor controlled label dispensing system and a sensing system for labels and products. The machine has the capability to label maximum 300 products per minute, based on the product and label size.

It even incorporates a specially designed mechanical and electronic system for applying transparent / no look labels on ampoules and vials, at a very high speed using an optional label sensing system. This is the only high speed rotary sticker labeling machine in India, with a distinct single point synchronized speed control system. Hence it has the highest installation in India. The inherent, preset label length detection system helps to eliminate the manual feeding and storage of label length details in the memory and retrieving the same data, every time for changing the label size and restarting the equipment. It thereby, saves your time, prevents machine down time, and assists to increase the production. The other salient features include, the exclusive feeding device for ampoules and vials in vertical position directly from the trays; and also collecting the labeled products similarly in a vertical position in the trays.

Moreover the user can even feed the ampoules/vials online for labeling without stopping the equipment. This latest feeding system thus eliminates the inconvenient and lengthy method of labeling ampoules/vials at the time of loading the products. It can be supplied with an online, linear packing line for vials that can be directly connected with the capping machine or turn table for constant feeding. This model is also available with an optional tough acrylic or glass safety cabinet.

No Label Data Input/retrievals require for any Label Size
No Change Parts for Label size
Single Pot On-line Speed Variation control
Synchronized speed of Label Dispensing, Product Feeding and Pressing Device
Virtually Maintenance free machine
Easy to change label application height
User Friendly Label Placing Adjustments
Self Protected against Voltage Fluctuations
Suitable for On-Line Inkjet and Contact Coding System
Suitable for Partial, Full Wrap Around and Overlap Labelling
Built In A.C. Variable Frequency Drive System.

Fully Stainless Steel finishes Machine

Label Roll Empty – Machine Stop System with Alarm
Missing Label in Roll – Machine Stop System with Alarm
Special Label Sensor for sensing Transparent Film Labels which does not have any sensing mark on it.
Option of Contact Coder, Hot Foil Coder, HP Cartridge Coder and Inkjet Coder with various speed ranges available.
Toughened Glass or Acrylic Safety Cabinet for Machine
Tower Light showing the machine status / operation
Colour or Mono Touch Screen with PLC for machine operation and showing various error messages and information on display
Special Sensing system for checking missing label on product
Low Compressed Air – Machine Stop with Alarm system for pneumatically operated coding system
Visison System for checking Barcode, presence or absence of Coding or Pharma code on labels
Vision System with OCR system for checking coding on labels
Online pneumatically operated product rejection system
