Verification of Ohm’s Law Series & Parallel Circuits.
Verification of Ohm’s Law Series & Parallel Circuits The board consists of the following built-in parts:
1. 0-15 VD.C. at 100 mA, continuously variable regulated Power Supply.
2. D.C. Voltmeter, 65mm rectangular dial to read 0-15V D.C.
3. D.C. Milliammeter, 65mm rectangular dial to read 0-50mA D.C.
4. Adequate no. of other electronic components.
5. Mains ON/OFF switch, Fuse and Jewel light.

• The unit is operative on 230V ±10% at 50Hz A.C. Mains.
• Adequate no. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ metre.
• Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections/observation of waveforms.
• Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
• Weight : 3 Kg. (Approx.)
• Dimension : W 340 x H 110 x D 210
