Contact SupplierWe are capable of entertaining the urgent and bulk requirements of the customers owing to the dependable logistics facilities. Ours is a quality driven company and strive hard to provide top-notch products to our worthy patrons. For this, we procure basic material from the trusted places only.
Features :
Boring Capacity (Standard) | Ø 48-Ø 96 mm |
---|---|
Boring Capacity (Optional) | Ø 38-Ø110 mm |
Spindle Speed (Variable) | 50-500 rpm |
Spindle Feed (Variable) | 0.06 mm/revolution |
Max Boring Head Travels | 300 mm (11.81") |
Max Distance from Spindle Centre to Column | 260 mm (10.23") |
Table Traverse (Longitudinal) | 500 mm (19.68") |
Table Traverse (Crosswise) | 40 mm (1.77") |
Working Table Size (L x W) | 500 x 250 mm (19.7" x 9.84) |
Spindle Motor Capacity | 0.75 kw/1 hp |
Rapid Motor Capacity | 0.19 kw/0.25 hp |
Height of Machine | 1550 mm (61.02") |
Length of Machine | 1100 mm (43.30") |
Width of Machine | 1000 mm (39.7") |
