Contact SupplierWe are offering single phase transformer lab trainer
experiments:
• study of 1 phase transformer connections
• efficiency test on 1 phase transformer
• ratio, voltage, power and current measurement in single phase
• open and short circuit test.
Features:
• electrical control panel with 1 single phase 1kva transformer.
• panel size 36x24 inches.
• transformer provided will be high quality copper wound.
• primary of transformer of 220v and secondary will be 110v.
• there are 3 tapping in the secondary at 50%, 86%, 100%.
• transformer will be differently housed in a ms powder cabinet for easy carrying and other general use.
• panel consist of ms powder coated housing with back side removable.
• panel fitted with front panel of insulated bakelite sheet 6mm thick.
• it is fitted with appropriate digital voltmeter, ammeter & wattmeter to record the readings.
• short circuit protection with the help of mcb.
• 4a variable ac supply is provided separately through variac for short circuit test.
• load bank is provided internally on panel with 100w electrical bulbs.
• connections through 4mm safety terminals.
• supplied with instruction manual
