Contact SupplierThe scrambler and un scrambler of stainless steel is popular as the turn table. The turn table is used for the synchronization of the process. The turn table fulfills the base for the uniform flow of the container. Its make easy to turn the container, 90 degree, to suit different application during operation in automatic liquid line.
HOW TO OPERATE :There is a S.S. strip to guide the containers to the forward procedure. The containers place on the turn table, manually or mechanically. There is a conveyor belt to move the containers on the table as per programmed.
Electrical Supply : Three Phase + Neutral + Earthing
Electrical Load : 0.5 KW
Â
Â
Model | APM-TT - 30 | APM-TT - 36 | APM-TT - 42 |
---|---|---|---|
Direction | Clockwise / Anti clock wise as per requirement | ||
RPM of Disk | 4/5/6 through step pulley | ||
Power Characteristics** | 0.5 HP/415 V/50 Hz | ||
Height of Disk** | 860 mm to 910 mm | ||
Machine Dimensions** | 780 x 780 x 1160 | 925 x 925 x 1160 | 1076 x 1076 x 1160 |
Case Dimensions** | 975 x 975 x 1300 | 1125 x 1125 x 1300 | 1300 x 1300 x 1300 |
Net Weight | 150 Kgs. | 175 Kgs. | 200 Kgs. |
Gross Weight | 300 Kgs. | 350 Kgs. | 400 Kgs. |
Container Size** | Round Container | Ø 22 mm to Ø 100 mm Respectively height 58 mm to 240 mm (Height option for other bottle height available) |
