Contact SupplierModel | HTC80 | HTC150 | HTC225 | HTC408 | HTC608 | HTC800 | HTC1000 |
Inside size WxHxD (cm) | 40x50x40 | 50x60x50 | 50x75x60 | 60x85x80 | 80x95x80 | 100x100x80 | 100x100x100 |
Outside size WxHxD (cm) | 90x136x94 | 100x146x104 | 100x161x117 | 110x171x137 | 130x181x137 | 150x186x137 | 150x186x157 |
Temperature | '-70℃~+100℃(150℃) | ||||||
range | (A:+25℃ B:0℃ C:-20℃ D:-40℃ E:-50℃ F:-60℃ G:-70℃) O9 | ||||||
Humidity range | 20%~98%R.H.(10%-98%R.H/5%~98%R.H is the specific codition) | ||||||
Heating / Cooling | About 4.0℃/min;about 1.0℃/min(5~10℃/mm is the specific condition) | ||||||
Insulation | High-temperature high-density amino acid ethyl ester foam insulation materials | ||||||
Cooling system | Air-cooled/ single-stage compressor(-20℃) ,wind, water cooled/ | ||||||
two-stage compressor(-40℃~-70℃) Protection | Compressor overload switch, high and low pressure protection switch, over-humidity-temperature protection switches, fuses, warning system | ||||||
Accessories | Recorder(purchase),view window,50mm testing hole,PL lamp, clapboard,Dry and wet gauze ball | ||||||
Power | 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz |
