Contact SupplierX,Y,Z axis working area | 1300*2500*180mm |
---|---|
Table surface | Cast Aluminum |
Structure | Mild Steel Fabricated |
Max. Operating speed | 25m/min |
Max. Engraving speed | 6m/min |
Resolution | 0.05mm |
Reposition accuracy | <0.03mm |
Command language | English |
Software running environment | Windows 2000, Windows XP |
Spindle power | 3.0kw |
Spindle rotating speed | 6000-24000m m/min |
Work Mode | Stepper motor |
Work voltage | AC220/50Hz |
Command | G code |
Guide | Square orbit for X Y and Ball Screw for Z axis |
Control System | DSP (Beijing) |
Guide Rail | PMI Brand (Taiwan) |
Software Compatibility | Type3,Artcam,castmate,ProE,UG etc. |
Optional | Panasonic Servo Motor, Spindle Power (4.5kw/ 5.5kw optional), Rotary Equipment |
