Steam Boiler

Listing ID #1344659

Get Latest Price

Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

We offer Steam Boiler that is mostly applied in areas where uninterrupted boiler operation is required. Steam Boiler features a Bi-drum that is used for generating saturated steam and superheated....

View More Details

Send Enquiry

Product Details

We offer Steam Boiler that is mostly applied in areas where uninterrupted boiler operation is required. Steam Boiler features a Bi-drum that is used for generating saturated steam and superheated steam. The Superheated steam is widely used for cogeneration or incidental power generation power in industries like Distilleries, Paper, Sugar, Solvent Extraction, Tea, Textiles, Rice, etc. Steam Boiler is fitted with various types of grates as per the availability and capacity of the boiler like Fluidized bed, Pulsating grate, Controlled air combustion, fixed grate, Traveling grate, Dumping grate, chain grate, etc. Dumping or pulsating grate is suitable for burning fibrous & moist fuels that are obtained from industrial wastes and agricultural residues whereas traveling grate is suited for burning low ash fuels in a Steam Boiler.
Product Range :

Capacity : 5TPH to 50 TPH
Pressure : 10.54kg/cm² to 87 kg/cm²(g)
Fuels : Wood, Coal, Briquettes, Sawdust,
Agro-waste like : Bagasse, rice husk, coffee husk, Macadamia nuts , palm shell, Groundnut shell, coconut shell, cotton waste
LDO, HSD, FO, LSHS, IDO, Natural gas, LPG, Biogas.(burner is provided for firing)

Special Features :

Bi-drum boiler is also called as Power generation boiler/Co-generation Boilers.
These Boilers are multifuel type boilers.
Automatic fuel handling with conveyors is possible.
Automatic as removal system can be easily incorporated.
Multiple doors are available for manual fuel feeding & ash handling.
Easy for installation& commissioning.
Air pre heater, water pre heater available to enhance output and efficiency
Accessories like Economisers can be provided to increase efficiency.
The furnace is also external to the boiler to enable combustion of high moisture agro-fuels like bagasse.
Particulate emission controlled using Multicyclone Dust Collectors

Company Details

Rakhoh is ISO 9001: 2008 certified by tuv india pvt. ltd . we are engaged in manufacturing of wide range of steam boilers, thermic fluid heaters, thermic fluid steam boiler & hot water boilers, coded pressure vessels, storage tanks, structural, water tube boiler components like, convection tubes, headers, super heater coils, economizer coils, drums, boiler accessories like economizers, air pre-heaters, wind turbine equipments, carriers and high capacity tower and nacelle lifting jigs etc. etc. equipped with latest technology, skilled labors and sound management, rakhoh has made a name for itself in the local as well as global market such as, east & central africa, srilanka, bangladesh and now embarking upon export to european countries. the company has representatives all over india, east & south africa, ethiopia and srilanka. we have also proved our turn key and site job fabrication capabilities, by successfully and timely completing plant fabrication, erection, & commissioning of the hot deep galvanizing plant for high mast towers plant with gimeco italy for m/s bajaj electrical ltd., pune. recently we are supplying one high pressure boiler to japanese company called ebara pumps ltd. for testing power turbine. we have also developed one high efficient boiler in this boiler era. this is the combination of water tube & smoke tube boiler in which furnace portion comprises of water tubes and this furnace is covered by water tubes from all 4 sides. this is the inherent advantage of this system. rakhoh counts many of the indian & foreign companies among its wide customer base. we are proud to serve markets such as petro chemicals, paper & pulp, food & beverage, pharmaceutical & biotech, automotive, transportation, textiles, wind mills and many more. partnering with each and every customer, we strive to understand their specific needs and design the best solutions quickly and efficiently. the variety and depth of market coverage combined with our extensive distribution channels make rakhoh 'india's boiler & specialty fabrication company'.
