Split Flow No Purge Loss Dryer

Listing ID #1177874

Get Latest Price

Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

We are a trusted Manufacturer and Supplier of Split Flow No Purge Loss Dryer from India. Our Split Flow No Purge Loss Dryer is known for its sturdy construction, durability and high performance.....

View More Details

Send Enquiry

Product Details

We are a trusted Manufacturer and Supplier of Split Flow No Purge Loss Dryer from India. Our Split Flow No Purge Loss Dryer is known for its sturdy construction, durability and high performance. These Split Flow No Purge Loss Dryers are offered at market leading prices.
Advantages

No purge loss.
No need of blower.
No used of external air thus eliminating risk of contamination.
Most economical in the range from 400 CFM onwards

Technical Specifications

Model No.	Capacity		Pipe Line size mm	Power Consumption KWH/DAY	Cooling Water Reqt. LPM	Approx. Overrall Dimensions
Model No.	M3 / HR	CFM	Pipe Line size mm	Power Consumption KWH/DAY	Cooling Water Reqt. LPM	Length mm	Width mm	Height mm
NPL - 01	1630	100	25	43.2	14	1600	1400	1800
NPL - 02	244.5	150	25	64.8	21	1800	1500	2000
NPL - 03	326	200	25	86.4	28	1800	1500	2000
NPL - 04	489	300	40	129.6	42	2000	1500	2200
NPL - 05	652	400	40	172.8	56	2000	1500	2200
NPL - 06	815	500	50	216	70	2000	1800	2200
NPL - 07	978	600	50	259.2	84	2200	1800	2400
NPL - 08	1222	750	65	324	105	2400	1800	2400
NPL - 09	1630	1000	65	432	140	2500	2000	2600
NPL - 10	2037	1250	80	518	175	2500	2000	2800
NPL - 11	2445	1500	80	648	210	2500	2000	3000
NPL - 12	3260	2000	10	842	280	3000	2000	3000
NPL - 13	4075	2500	10	1030	350	3000	2000	3000

Download Detail File : Click Here

Graph

Download Detail File : Click Here

Company Details

Air-N-Gas Process Technologies was established in the year 2007, with an aim to boost the technical advances in the field of Adsorption based Gas Separation Systems, Air Filters and Air Dryers. In this short span of time, we have earned ourselves a niche in the air dryers industry and have established a great rapport amongst the leading manufacturers, exporters, traders and suppliers. Supported by a group of efficient technocrats, we are headed by Mr. Shailesh Verma (B.Tech-Mech, DMM), who has accumulated a rich experience of more than 17 years in the respective field. Today, we have emerged as a specialized concern in designing, manufacturing, exporting, site installation and commissioning of a varied range of products like Nitrogen/Oxygen Gas Generators, Compressed Air Drying Units, High/Low Pressure Dryers, Air Filters, After Coolers, Auto Drain Valves, Air Receivers, Pressure Vessels, Air & Water Chillers, etc.
