Listing ID #3420536
Company Information
Ask for more detail from the seller
Contact SupplierTechnical Specifications
Model SI-102 SI-104
Display Data : 3 12 digit LED Display
3 digit display for Wavelength Data : 3 12 digit LED Display
3 digit display for Wavelength
Range 340 to 960 nm 340 to 960 nm
Resolution 0.1%T, 0.001 Abs, conc.1 0.1%T, 0.001 Abs, conc.1
Output %T: 0 to 100%, Abs; 0 to 1.999, Conc. 0 to 1999 %T: 0 to 100%, Abs; 0 to 1.999, Conc. 0 to 1999
Detector Silicon Photodiode Silicon Photodiode
Monochromator 600 Lines mm holographic grating 600 Lines mm holographic grating
Sample Holder 10 mm 10 mm and 50mm path Length facility.
Spectral Bandwidth 5 nm 5 nm
Wave Length Resolution 1 nm 1 nm
Wave Length Accuracy 2.5 nm 2.5 nm
Repeatability 2 nm 2 nm
Power 230V &±10 % AC 50 HZ 230V 10 % AC 50 HZ
Dimensions L475 x B290 x H190 mm L475 x B290 x H190 mm
Weight 8 kg (approx.) 8 kg (approx.)
Accessories Cuvtte - 10mm (dia.) 10no, Dustcover, Operation Manual. Cuvtte - 10mm & 50mm, Dustcover, Operation Manual.
