Sparkler Filter Press

S F SPARKLER FILTER Totally enclosed air sealed leak proof filtration plant assembly. It consists of a filter cartridge assembly having material of construction Mild Steel filter plates, support screen, having interlocking cups and fitted in the Main shell tank. Filter is equipped with special arm device in Mild steel for quick opening of filter lid cover. Unit provided with all interconnecting pipelines and Ball valves having inlet/outlet/transfer/air vent, valve pressure gauge assembly, and suitable pump with ISI make FLAME PROOF motor, with �V� belt and pulley drive. The whole unit is mounted on MS fixed base.
SALIENT FEATURES:
� Manufactured From Stainless Steel 304 Construction.
� CI Gear Pump SIZE 1 ½� x 1 ½ �
� M.S. Jacket is provided for hot filtration & Cooling.
� Provided with bypass system & safety valve.
� Complete Mild Steel Base plate.
OPERATION:
The liquid to be filtered is pumped to the tank, where it enters into the individual plates. It passes through the filter media (Paper/Cloth) and crystal clear filtrate comes out through a central channel formed by interlocking cups. The cake formed between the plates can be obtained if required.
