Contact SupplierThe advanced cell processing technology and automated production facilities produce a highly efficient photovoltaic module. The conversion efficiency of the solar cells reaches up to 15%. These cells are encapsulated between a tempered glass cover and an EVA (Ethylene Vinyl Acetate) with back sheet to provide maximum protection for all environmental conditions. The laminated parts, equipped with plug in connectors are installed in an anodized aluminium frame to provide structural strength and ease of installation.
Applications:(Long term output warranty shall guarantee that loss of output is not more than 10% of the minimum warranty value of the product specifications within 10 years and is not more than 25% within 20 years after the purchase of the product by customer)
Model No. |
Voltage (V) |
Wattage (Wp) |
No. of Cells |
Weight (Kg) |
Terminals |
Dimension in mm (LxWxH) |
LWC0603 |
6.0 |
03 |
18 |
0.8 |
2 T |
235 x 185 x 17.5 |
LWC0605 |
6.0 |
05 |
18 |
1.0 |
2 T |
345 x 215 x 17.5 |
LWC1205 |
12.0 |
05 |
36 |
1.0 |
2 T |
345 x 215 x 17.5 |
LWC1210 |
12.0 |
10 |
36 |
1.3 |
2 T |
345 x 305 x 17.5 |
LWC1218 |
12.0 |
18 |
36 |
3.0 |
2 T |
655 x 295 x 35 |
LWC1220 |
12.0 |
20 |
36 |
3.0 |
2 T |
655 x 295 x 35 |
LWC1230 |
12.0 |
30 |
36 |
3.5 |
2 T |
415 x 655 x 35 |
LWC1237 |
12.0 |
37 |
36 |
4.3 |
2 T |
540 x 655 x 35 |
LWC1240 |
12.0 |
40 |
36 |
4.3 |
2 T |
540 x 655 x 35 |
LWC1250 |
12.0 |
50 |
36 |
6.0 |
3 T |
705 x 655 x 35 |
LWC1260 |
12.0 |
60 |
36 |
6.2 |
3 T |
775 x 655 x 35 |
LWC1274 |
12.0 |
74 |
36 |
7.5 |
3 T |
905 x 605 x 35 |
LWC1280 |
12.0 |
80 |
36 |
7.7 |
3 T |
1005 x 655 x 35 |
LWC12100 |
12.0 |
100 |
36 |
9.9 |
3 T |
655 x 1240 x 35 |
LWC12125 |
12.0 |
125 |
36 |
11.3 |
3 T |
1475 x 655 x 35 |
LWC12130 |
12.0 |
130 |
36 |
11.5 |
3 T |
1475 x 655 x 35 |
LWC24100 |
24.0 |
100 |
72 |
11.0 |
3 T |
930 x 971 x 35 |
