Contact Supplier» Specifications
Telescope | |
Length | 215 mm (8.46in.) |
Magnification | 28x |
Objective aperture | 36 mm (1.42in.) |
Resolving power | 3.5" |
Field of View (at 100m/32Bft.) | 1o 25' (2.5m / 8.2 ft.) |
Minimum focus | 0.2 (7.9in.) from end of telescope 0.3m (1ft.) from instrument center |
Image | Erect |
Reticle pattern | Cross line |
Stadia constant | 0 |
Stadia ratio | 100 |
Focusing knob | 1 – Speed |
Sighting aid | Peep Sight |
Lens hood | - |
Accuracy (standard deviation for 1km double run leveling) | |
Without micrometer | 1.5mm (0.06in.) |
With micrometer | - |
Compensator | |
Type | Pendulum Compensator with magnetic damping system |
Setting accuracy | 0.5" |
Working range | ± 15' |
Circular level | |
Sensitivity | 10' / 2mm |
Mirror | Plane mirror |
Horizontal circle | |
Diameter | 103 mm (4.1 in.) |
Graduations | 1o / 1 gon |
General | |
Horizontal rnotion drive | Clampless, endless, double-sided knobs |
Water resistance | IP x 6 (IEC 60529:2001) |
Operating temperature | - 20 to + 50oC (-4 to +122oF) |
Size | Width - 130mm (5.12in.) Length - 215mm (S.46in.) Height - 140mm (5.51in.) |
Weight | 1.7kg (3.7 Ib.) |
