Epoxy mixing com Casting Plant, for Industrial, Voltage : 220V, 380V, 440V

Listing ID #6521031

Epoxy Mixing Cum Casting Plant Resin casting is a method of casting where a mould is filled with a liquid synthetic resin, which then hardens. The synthetic resin for such processes is a monomer for making a thermosetting polymer. During the setting process, the liquid monomer polymerizes into the polymer, thereby hardening into a solid.

Our resin casting plant is manufactured using quality components and spare parts to ensure optimum performance and long functional life. Resin casting plant is integrated with mixing chamber, which is designed with heating system with temperature controlling arrangement.

The simplest method is gravity casting where the resin is poured into the mold and pulled down into all the parts by gravity inside a vacuum chamber. The casting is done in a vacuum chamber to extract the air which avoids formation of air bubbles.

The mixing chamber with circular cone-shaped bottom is heated with an oil jacket, the temperature being measured and controlled continuously. The temperature of the wall is hence uniform. A stirrer with baffle rotating at the correct speed which gives shearing action causes thorough resin filler mixing. The agitation exposes all the mix to vacuum& thus degassing is thorough. The mixing paddle drive is with 3 phase motor & reduction gear. The shaft seal is robust rotary seal with tapered roller bearings. The pouring valve is made of P.T.F.E. (Teflon) & this makes cleaning easy. Trap is used to very effective stop abrasive filler particles from entering & ruining the vacuum pump.

Features :

• Mixing chamber for mixing of resin, with hardener, accelerators, pigment and filters, of capacities from 5kg to 1000kg, designed for high vacuum degassing.
• It is designed with heating system having precise temperature controlling arrangement for controlling the exotherm during mixing, as required.
• Casting chamber, adequately sized to accommodate desired number of moulds, designed for pouring resin under high vacuum.
• Pouring system designed for vacuum casting with easy control and observation from outside, with specially designed PTFE valves.
• The plants can be offered continuous production process.

Applications :

• CT and PT manufacturer
• Dry type transformer etc

FAQ

Q1.Why choose us?
A1:We are specialized in packing scale for more than 15 years production experience.
Q2. How''s your oversea markets?
A2: Our machine have sold to Colombia,Ecuador,Pakistan,Bangladesh,Vietnam,Thailand,Indonesia,Myanmar etc.We are expanding our business and very glad to cooperate with you as our partners or our agent.
Q3. How do you control the quality?
A3: Professional QC team comply with TQM insure you the quality. Each step is in compliance to the standards,At the same time ,we will take photos or shoot video for you.
Q4. What is your terms of payment ?
A4:We accept West Union, T/T, irrevocable L/C at sight. Prefer T/T 30% deposit before production, the balance against copy of B/L.
Q5.What about lead or shipping time?
A5:The lead time depends on the quantity you ordered, generally within 15-20 days upon receipt of advance payment.
Q6. What about the service offered by company
A6:We have the professional engineer team which can design and develop the mold to arrive different customer requirement.We also have the sales team to offer good service from pre-sale to after-sale.
