Semi Automatic Multijet Ampoule Washing Machine

Listing ID #3921476

  • Supply Type Manufacturer, Exporter, Supplier
  • Preferred Buyer Location All over the world

As one of the pioneering manufacturers of Semi automatic multijet ampoule and vial washing machine, Harsiddh Engineering Co. offers products of highest quality standards. The S.S construction....
View More Details
Send Enquiry

Company Information

  • Member Since 7 Years
  • Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

As one of the pioneering manufacturers of Semi automatic multijet ampoule and vial washing machine, Harsiddh Engineering Co. offers products of highest quality standards. The S.S construction provides lucid operation while washing ampoules of 1ml to 25ml. additionally; the washing equipment also meets the washing demands of 2ml to 100ml vials. Microprocessor incorporation enhances the functioning of the entire unit.



The washing apparatus possesses incredible technical specifications. The needle quantity of the machine is classified in 30 cycles in every hour. With a power consumption capacity of 0.25HP, this particular equipment consumes very less power. The entire machinery works on the pressure cleaning mechanism and makes very less use of the washing media. Operators can also view the entire washing process with the acrylic cover placed on the top of this ampoule washing device. By using distilled water, this device ensures perfect cleaning for all kinds of vials and ampoules. Apart from that, the machine also offers lucid operation by loading 30 trays within an hour. Our machines have CE certifications.



Automatic re-start and stop process during the cyclic operation further enhances your convenience while washing. Additionally, all the contact parts of the equipment exhibit S.S 316 or HDPE polycarbonate materials, thus imparting robust strength.

Silent Features

  • Machine is suitable for washing of 2ml to 100ml vials.
  • High pressure spray nozzles enter into the vials & ensure perfect wash.
  • Totally fabricated from high quality SS materials including the basic frame.
  • No change of parts required for washing of vials (5ml to 30ml), hence saving time of change over.
  • All parts coming in contact with washing zones / jets are made from SS 316 material.
  • Water re-cycling arrangement is possible as per customer’s requirement.
  • Machine is totally robust and withstand continuos operation for long working hours without any trouble.
  • Multijet ampoule and vial washing machine is equipped with PLC system & printing facility with passwords.




Production Rate Up to 120 Containers/Min.(HTVW 120) Up to 240 Containers/Min.(HTVW 240)
Input Specification Container Dia.:15mm to 56mm Container Height:25mm to 110mm
Power Specification 3 H.P, 3 Phase, 4 Wire System, 50 Hz.
Optional Accessories Loading Platform Utility
Overall Dimension 2290mm (L) X 1175mm (W) X 1575mm (H) (HTVW 120) 2290mm (L) X 1580mm (W) X 1975mm (H) (HTVW 240) Net Weight: 1200 Kgs, Gross Weight: 1700 kgs.

Company Details close-icon

Harsiddh Engineering Co. is a world renowned Pharmaceutical Machines manufacturer and Supplier in India. The company has established in Ahmedabad since 1988; initiated its operation under the name of Persist Pharma Engineers and have grown manifold over a period of time with increasing products portfolio. The organization restructured in 2005 to shape its strong presence in International market with a new Name Harsiddh Engineering Co., and till then constantly exploring its technical expertise in pharmaceutical industry on domestic and global platform.
Ampoule line machineries including ampoule filling machines are the first line products from beginning, adding up with liquid and powder injection machineries in our latest portfolio. Quality and customer satisfaction are our main concern that is continuously evolved at various production stages, which is reflected in the reviews of our regular domestic as well internationals buyers. Our dedication, efficiency and quality production have earned the company an ISO 9001:2008 certification and many awards. Our products have CE certification and DUNS number. We are also an active member of Engineering Export Promotion Council of India.
