The unit consists of a Dilution Chamber, followed by a Heat Exchanger. Dilution Chamber is used for diluting concentrated Sulfuric acid to the desired concentration and the Heat Exchanger is used for bringing down the temperature of dilute acid to desired temperature (When the concentrated acid mixes with water, large amounts of heat are released). The Heat Exchanger is of Shell and Tube type to dilute the acid.
The acid should be added slowly to cold water to limit the buildup of heat. If water is added to the concentrated acid, enough heat can be released at once to boil the water and spatter the acid. Sulfuric acid reacts with water to form hydrates with distinct properties.
The system consists of :

• Dilution Chamber with accessories -Glass.
• Heat Exchanger – Glass.
• Glass Buffer as Receiver & Circulation of dilute acid (Optional).
• Dilute Sulfuric acid Circulation Pump (Optional).
• Glass Pipelines, Valves, & Fittings and Therm o well.
• Non – Return Valve for Acid & Water Inlet.
• Expansion Bellows In PTFE for all Nozzles of Glass Components.

Outstanding Features :

• Continuous method of producing the broad range of sulfuric acid grades (Dilute sulfuric acid from 98% to 10% ~ 15%)
• The all Glass & PTFE construction of plant eliminates the material corrosion and allows this profitable operation to take place safely.
• The unit can be offered vertical or horizontal as per site layout.
• Compact design. The equipment is simple and easy to operate.
• Control outlet acid temperature 6. Design temperature: 160 Deg C
