Secondary Cone Crusher

Listing ID #4353803

Get Latest Price

TypeSecondary Crusher
Input Size0-200mm
Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Product Details

1.The plant is designed with ship-form structure made of steel and low chassis.It is light in weight.Owning to the reasonably designed body,its transportation turning radius is quite small with high maneuverability.
2.The vehicle control cabinet is equipped with high-tech LCD touch screen and PLC control system.LCD touch screen with human-machine dialogue function makes it process the functions of key start,misuse warning,protection,electrical control operations,fault and safe tips,which is convenient,high-efficient and secure.
3.The automatic-portable conveyor for return material make the installation of the whole plant quite easy.
4.Landing legs adopt hydraulic lift mode which is of convenient operation and reliable performance.
5.The mobile crushing&screening plant can be customized in design.It can be manufactured either crushing first or conversely.

Features

1.High capacity
2.High performance of secondary crushing
3.Flexible
4.Integral crushing&screening
5.Belt conveyor self-loaded

Processed Materials :
Iron ore, copper ore, gold ore , manganese ore, limestone, granite, basalt, andesite, quartz, silica, gypsum, volcanic rock, marble, river stone, gravel, coal etc..

Applications :
Secondary medium & fine crusher is widely used in mining, quarry, mixing and batching plant, road and building construction, highway, railway and subway, and water conservancy.

Technical Data//Model		Y3S1848CS75	Y3S1860CS160	Y3S1860HP220	Y3S2160HP220
Transportation size(mm)		12000x2800x4300	13400x2820x4350	13400x2820x4350	13400x2820x4350
Weight(t)		28	46	42	43.5
Tire Configuration		Dualaxial	Triaxial	Triaxial	Triaxial
Cone Crusher		CS75	CS160	HP220	HP220
Discharging Belt Conveyor		B800×6M	B800×8M	B800×8M	B1000×8M
Vibrating Screen		3YZS1848	3YZS1860	3YZS1860	3YZS1860
Electric control	standard	control box + control panel	control box + control panel	control box + control panel	control box + control panel
Electric control	Optional	Control box + LCD	Control box + LCD	Control box + LCD	Control box + LCD
Hydraulic leg	standard	4	4	4	4
Hydraulic leg	optional	2	2	2	2
Hydraulic cycliner	standard	0	0	0	0
Hydraulic cycliner	Optional	2	2	2	2
Genset(optional) (Kw)		180	320	440	440
