Contact SupplierThe company has come up as a prominent Importer and Supplier of SC/V Series Heavy Duty High Thrust Actuator, which come with a mechanical spring for safe positioning. The SC/V Series Heavy Duty High Thrust Actuators can deal with the air supply failure and the fabricated steel body adds sturdiness. The SC/V Series Heavy Duty High Thrust Actuators may have varying stroke and thrust requirements and they may be available with single or multiple coaxial springs as well as numerous springs placed on a certain actuator circumference.
Details
Cylinder | carbon steel |
---|---|
Cover and tie rods | carbon steel |
Piston | carbon steel |
Shaft | stainless steel |
Springs | alloy steel |
Thrusts | from 2.600 to 30.000 daN (referred to nominal thrust; depending on selected spring rate and pre-compression thrust can vary considerably. |
---|---|
Standard Sizes | 260,330,420,520,600,650,800,850 mm |
Stroke | 100 to 400 mm |
Operating Temperature | -26 to +80oC (-15 to + 176°F) (lower or higher temperature available on request) |
Supply Pressure | max. 1.000 kPa |
Supply Media | dry instrument air or clean gases |
Standard Connections | 1/2" NPT F (1/4" NPT F for sizes 260 and 330) (larger connections available on request) |
