Contact SupplierMachine Type | 13 D | 9 D |
Inlet diameter | dia.8 | dia.8 |
Outlet diameter | dia. 1.2-dia. 3.2 | dia. 1.2-dia. 3.2 |
Drawing line speed | 1200 | 600 |
Drawing dies No./Max. | 13 | 9 |
Slip ratio of m/c | 23.6% | 23.6% |
Fix speed capstan slip ratio | 20% | 20% |
Capston | Tungsten | |
Capston dia. (Max.) | dia. 450 | |
Fix Speed Capston dia. | dia. 450 | |
Frame | Weld, Two conjunctions | |
Main Motor | 250 KW, DC Motor 160 KWm, DC Motor | |
Spooler motor | 15 KW Three phase inductor motor | |
Revise system | PID synchronous spooler | |
Inverter Control | DC speed regular + dual inverter cntrol | |
Transmission type | Gear | |
Send-out-method | Over head | |
Traversing unit | Dcelerate motor | |
Tension control | Pneumatic balance by swing arm | |
Lubrication system of wire drawing |
All mmerse type | |
Suitable diameter of spool | dia. 800 pay-off frame in coils | |
Capacity for wire receiving | 200-1800 | |
Power source | 380 V | |
Brake | Pneumatic brake |
