| Stand | C shaped, corrosion resistant, Anti mould treated |
|---|---|
| Viewing Head | Gemel-Style Binocular / Trinocular Tube, Inclined 30 degree ,360 degree Rotatable, Interpupillary Distance:55-75mm |
| Eyepieces | High Eyepoint, Wide Field, Viewing Adjustable Wide Field Eyepieces 1 WFIOX (Field of Line 20mm), Optional WF16X, WF20X |
| Nosepiece | Inner inclined Quadruple Nosepiece or Quintuple Nosepiece |
| Objectives | SA Series -Semi-Plan Achromatic Objectives: 4X,10X,40X(S),100(O,S) PA Series- Plan Achromatic Objectives: 4X,10X,40X(S),100(O,S) IPA series- Infinite Plan Achromatic Objectives: 4X,1OX,40X(S),100(O,S) |
| Working Stage | Double Layers with Mechanical Sliding Stage, Triangle Iron Moving Up and Down Area:160mm x 142mm, Moving Range;76mm(X) x 52mm(Y) |
| Focusing System | Coarse and Fine Focusing Coaxal , Coarse Degree of Tightness Basised of Your Custom, Coarse Range: 25mm, Fine Precision Scale: 0.002mm |
| Condenser | Abbe Condenser N.A = 1.25 with Iris Diaphragm and Filter Holder, Moving Up and Down, Center Adjustable |
| Illumination | Built-in Critical, Halogen Lamp,12V/20W, Brightness Adjustable Optional LED Light Source, Brightness Adjustable |
| Optional Objectives | 25X, 60X ( S ).Camera Adapter, CCD Adapter, Digital Camera Adapter, Dark Field Unit, Phase Contrast Unit, Polarizing Unit, EPI- Fluorescence |
