This is a general purpose batch unit which is operated at atmospheric pressure or vacuum.
This unit is used for carrying out reactions under stirred condition and with provision for simple reflux distillation.
The reaction vessel is mounted in a heating bath and fitted with addition vessel, motor-driven stirrer and provision for condensation with refluxing. The product is sub-cooled and collected in a receiver.
The units are available in vessel sizes of 20, 50, 100 & 200L and is suitable for operation under atmospheric pressure and full vaccum.
Â
Unit Cat. Ref.
Reactor Capacity
Bath KW
Addition Vessel
Vapour Line
Condenser HTA M2
Cooler HTA M2
Receiver Size
RDU20
20 L
4.5
2 L
80 DN
0.35
0.10
5L
RDU50
50 L
6.0
5 L
100 DN
0.50
0.20
10L
RDU100
100 L
9.0
10 L
150 DN
1.50
0.35
20L
RDU200
200 L
12.0
20 L
150 DN
1.50
0.35
20L
RDU300
300 L
16.0
20 L
225 DN
2.50
0.50
20L
