Contact SupplierBrand | Smarten |
Solar Panel Type | Polycrystalline |
Wattage (Wp) | 400 watt |
Operating(Nominal) Voltage | 24V |
Open Circuit Voltage (Voc) | 48.5V |
Short Circuit Current (Isc) | 9.95A |
Country of Origin | Made in India |
Package Dimensions | 1960mm x 990mm x 40mm |
Maximum Power at STC (Pmax) | 24V/400Wp (-0 to +3%) |
Voltage at maximum power (Vmp) | 39.8V |
Current at maximum power (Imp) | 9.50A |
Maximum Module Efficiency (%) | 19.32% |
Operating Temperature | 40 degree Celsius to +85 degree Celsius |
Maximum System Voltage | 1500VDC |
Maximum Series Fuse Rating | 15A |
