We are engaged in offering Portable Data Loggers that are available with 4 to 8 analog input channels for measuring various things like current, resistance, temperatures, etc. Our Portable Data Logger also comprises of 8 digital channels for automatically triggering or stop logging. Further, a port is also included in it, which allows one to connect any external networking or modem. Our Portable Data Loggers is suitable for bench top and fixed installations. This Portable Data Logger is ideal for meeting various data logging needs. For the ease of the clients we offer Portable Data Loggers at industry leading rates.
AttributesCan be easily programmedFour integral push buttonsLarge graphical displayIncluded windows softwareUsed To MeasureCurrentsVoltageResistance TemperatureFeatures4 to 8 Universal Analog Inputs (Current, Voltage, Resistance, Temperature) Plus 8 Digital Inputs16 Derived/Calculated Channels2 Alarm Outputs and 2 Pulse Counter Inputs (1 at 64 KHz, 1 at 100 Hz)0.1% AccuracyUp to 1.8 Million ReadingsLarge Easy-to-Read Graphical DisplayIncludes Windows® Software for Data Logger Setup and Data Transfer to PCUSB ConnectivityRS-232 Output For Modem and Wireless Connection (Via Interface Modules)
Comprehensive Software Configuration
The OM-SQ-SOFT software (supplied with the VI-UI-2010 series data loggers) allows logger configuration, data download and data export while giving the user full control over the VI-UI-2010. The optional VI-DAQMATE software gives the user access to many advanced data analysis and data archiving/transfer features.
The optional VI-DAQMATE software lets you quickly and easily analyze the data from your VI-UI-2010 data logger in a familiar windows explorer style interface. Data can be displayed with 2 different auto scaling Y-axis. This is particularly useful when displaying widely varying data from different sensors on one graph. You can also zoom in on areas of interest, use a cursor to pick out exact values, times and dates, get a statistical summary of your data, set high and low alarm thresholds and, using the calculation function, you can create new virtual channels from existing channels.
The VI-DAQMATE software also incorporates a report generation facility, which allows you to create custom report templates consisting of a title page with descriptive text, headers and footers, graphs, tabular list of data, statistics and data logger setup information. Templates can be setup with any of these combinations and saves time when preparing similar presentations of data.
Part of the OM-SQ Family of Data Loggers
If the VI-UI-2010 does not have the exact features you are looking for there are two other data loggers in the OM-SQ family with additonal features.
VI-UI-816 Portable Data Logger with 8 to 16 Universal InputsVI-UI-816/2/4/8 Portable Data Logger with 8 or 16 Universal Inputs Plus 2 High Voltages, 4 Pulse and 8 DigitalEvent/State Inputs
| No. of Analog Channels | 8 single ended or 4 differential inputs. The VI-UI-2010 data logger has a single analog to digital converter (A/D) which corresponds to inputs on blocks A and B. Each connection block will accept up to 2 differential inputs or up to 4 single ended inputs (it is not possible to mix single ended and differential inputs on a block). |
|---|---|
| Analog Input Connections | Detachable srew terminal blocks |
| Channel Expansion | No |
| Universal Input | Yes |
| Voltage Ranges (Differential and Single Ended) |
|
| Common Mode | 25 V |
| Current Ranges, Differential (Requires External 10 O Shunt) | 4 to 20 mA,+30 mA |
| Thermocouple Ranges (Differential and Single Ended) |
|
| Resistance Ranges (All 2 Wire) | 0 to 1250 O, 0 to 5000 O 0 to 20,000 O, 0 to 300,000 O |
| Thermistor Ranges: U & UU-Type | -50 to 150oC (-58 to 302oF) |
| Y-Type | 50 to 150oC (-58 to 302oF) |
| S-Type | 30 to 150oC (-22 to 302oF) |
| User-Defined Thermistor | Enter Steinhart-Hart coefficients or RT pairs |
| Pt100/1000 (2-wire) | -200 to 850oC (-328 to 1562oF) |
| A/D Resolution | 24 bit |
| Accuracy | See table on PDF |
| Internal Reference Temperature | -50 to 150oC (-58 to 302oF) |
| Pulse Count Ranges | 0 to 100 Hz (1 input); 0 to 64 kHz (1 input); 0 to 16,000,000 count |
| Digital State/Event Ranges | 8 state inputs or 1 x 8 bit binary |
| Digital/Alarm Outputs | 2 open drain FETs, 18V, 0.1A |
| Digital I/O Connections | DB25F connector |
| Clock Resolution/Accuracy: 1s/10 ppm Normal Mode | Each input sampled at a max rate of 1 rdg per second |
| Double-Speed (Mains Reject Off) | One input can be sampled at 10 rdgs per second and all others are sampled at a max rate of 1 rdg per second |
| No of Intervals | 4 |
| Data Scaling | Included in standard OM-SQ software |
| Data Statistics | Calculated within VI-DAQMATE software |
| Calculated Channels | Up to 16 |
| Memory Internal | 16 M (1 to 1.8 million readings) |
| Display/Keypad | 128 x 64 dot graphical display, 4 button keypad |
| Power | 2 C cells internal (included), or external 8 to 28 Vdc via AC adaptor and USB when plugged in |
| Battery Life | Up to 5 days with continuous usage while sampling all channels once per second |
| Sensor Power Output | 5 V at 50 mA, external 8 to 28V at 100 mA (when connected) |
| Networking | Via RS-232 to Ethernet adaptor (Model No. OM-SQ-NET-ADAP) |
| Modem Support | Via RS-232 modem (GSM modem kit Model No. OM-SQ-GSM-KIT) |
| PC Setup | Complete data logger set up possible via OM-SQ software; software compatible with WIN 98/2000/XP/VISTA |
| Front Panel Setup | Via 4 integral 4 keys. All essential functionality available via key pad e.g. channel configuration, start/stop logging etc. Other advanced functions e.g. calculated channels and channel descriptions are available via connection to a PC running OM-SQ data logger software |
| Stored Setups | 6 |
| Operating Temperature | -20 to 65oC (-4 to 149oF) |
| Dimensions | 135 H x 175 W x 55 mm D |
| Weight | 0.7 kg (1.5 lb) |
| Enclosure | ABS plastic |
