Specifications
Model | Motor Hp | RPM | Max Cap M3/Hr. | Max Head in M | Suction (mm) | Discharge (mm) |
P-22-100-H | 1.00 | 2900 | 0 - 6.5 | 13 - 0 | 25 | 25 |
P-44-120-H | 2.00 | 2900 | 0 - 24 | 18 - 0 | 40 | 40 |
P-44-150-H | 3.00 | 2900 | 0 - 22 | 24 - 0 | 40 | 40 |
P-47-160-H | 5.00 | 2900 | 0 - 32 | 33 - 0 | 75 | 40 |
P-57-170-H | 7.50 | 2900 | 0 - 60 | 34 - 0 | 75 | 50 |
P-47-210-L | 3.00 | 1440 | 0 - 33 | 15 - 0 | 75 | 40 |
P-45-190-H | 10.00 | 2900 | 0 - 58 | 49 - 0 | 50 | 40 |
P-57-210-L | 5.00 | 1440 | 0 - 52 | 16 - 0 | 75 | 50 |
P-57-185-H | 20.00 | 2900 | 0 - 96 | 42 - 0 | 75 | 50 |
P-44-205-L | 2.00 | 1440 | 0 - 26 | 12 - 0 | 40 | 40 |
Spares Parts List
Description | M.O.C |
Volute Casing | P.P |
Back Plate | P.P |
Impeller | P.P |
Suction Flange | P.P |
Adopter | C.I. |
Cage Ring | C.I. |
Hardware Set for Volute Assly. | SS |
Flange for Back- Plate | P.P |
Bush | GFT |
Drip - Tray | FRP |
Stationary Ring for Mach.Seal -1 3/8" | Ceramic |
Location Flange | Back Plate |
Pp Coated Nut - 3/8" BSW | PP/MS |
Leg Support for Bearing House | C.I |
Ball Bearing 3306 Motor Side | STD |
CIR.Clip | Steel |
Oil Seal 40x25x10 Motor Side | Neoprene |
Lock Nut with Lock Washer | Steel |
Bare Shaft | EN 8 |
Bearing Cover | C.I |
Bearing Housing | C.I |
Ball Bearing 6207 Pump Side | STD |
Oil Seal 35x72x10 Pump Side | Neoprene |
Deflector | PP/MS |
Shaft Sleeve for 1 3/8" Seal | Ceramic |
Rotary Unit for Mach.seal | TEF. Bellows |
Washer for Stationary Part of Mach.seal | PTFE |
Bolts for Location Flange | SS-316 |
"O" Ring | Vition |
Gland Ring ( One Set = 4 Ring ) | Gratified Fill Teflon |
Gland Pusher | Bake Lite |
Gland House | GFT |
Location Flange | Bake Lite |
Back Plate With Bush For Gland Set | PP |
