Contact SupplierFor making sure about the safety of the products during handling,transporting and warehousing, we make use of quality packaging material. And, this task is accomplished by our deft professionals. As a promising name, we bring forth high quality product range that is designed and developed using the best in class raw material and modern work methodologies. Besides, we make sure that the basic material is sourced from the trusted places.
Specifications
Model | Thick Ness (MM) |
Length (MM) |
Length Between Housing (MM) |
Depth of Gap In Frame (MM) |
Number of Stroke Per Minute |
Cutting Angle |
Max. Back Guage Adj. (MM) |
Motor (H) |
Approx. |
---|---|---|---|---|---|---|---|---|---|
UC / 1250-4 | 4 | 1250 | 1600 | 100 | 55 | 2o | 600 | 5 | 2500KGS. |
UC / 1250-5 | 5 | 1250 | 1600 | 100 | 50 | 2o |
600 | 7.5 | 3200 KGS. |
UC / 1500-4 | 4 | 1500 | 1850 | 100 | 55 | 2o30' | 600 | 7.5 | 3000 KGS. |
UC / 1500-5 | 5 | 1500 | 1850 | 100 | 50 | 2o30' | 600 | 10 | 3800 KGS. |
UC / 2000-3 | 3 | 2000 | 2350 | 100 | 50 | 2o30' | 600 | 7.5 | 3700 KGS. |
UC / 2000-4 | 4 | 2000 | 2350 | 100 | 50 | 2o30' | 600 | 7.5 | 4000 KGS. |
UC / 2000-5 | 5 | 2000 | 2350 | 100 | 50 | 2o30' | 600 | 10 | 4500 KGS. |
UC / 2500-3 | 3 | 2500 | 2850 | 100 | 50 | 2o30' | 600 | 10 | 4200 KGS. |
UC / 2500-4 | 4 | 2500 | 2850 | 100 | 50 | 2o30' | 600 | 10 | 4500 KGS. |
UC / 2500-5 | 5 | 2500 | 2850 | 100 | 50 | 2o30' | 600 | 12.5 | 5200 KGS. |
UC / 3125-4 | 4 | 3125 | 3500 | 100 | 50 | 2o30' | 600 | 12.5 | 5800 KGS. |
UC / 3125-5 | 5 | 3125 | 3500 | 100 | 50 | 2o30' | 600 | 15 | 6200 KGS. |
