Contact SupplierSize (In) | Size (Mm) | ØD | ØD1 | ØD2 | ØD3 | T |
---|---|---|---|---|---|---|
1 x ½ | 32x20 | 32 | 22 | 14 | 20 | 48 |
1x ¾ | 32x 25 | 32 | 22 | 17 | 25 | 50 |
1.1/4x1/2 | 40x20 | 40 | 28 | 15 | 20 | 51 |
1.1/4x3/4 | 40x25 | 40 | 28 | 14 | 25 | 53 |
1.1/4x1 | 40x32 | 40 | 28 | 22.5 | 32 | 55 |
1.1/2x1/2 | 50x20 | 50 | 34 | 12.5 | 20 | 55.5 |
1.1/2x3/4 | 50x25 | 50 | 40 | 20 | 25 | 57 |
1.1/2x1 | 50x32 | 50 | 34 | 20 | 32 | 55 |
1.1/2x1.1/4 | 50x40 | 50 | 34 | 30 | 40 | 57 |
2x1 | 63x32 | 63 | 45 | `21 | 32 | 76 |
2x1.1/4 | 63x40 | 63 | 45 | 28 | 40 | 85 |
2x1.1/2 | 63x50 | 63 | 44.5 | 32 | 50 | 74 |
2.1/2x1 | 75x32 | 75 | 55 | 20 | 32 | 82 |
2.1/2x1.1/2 | 75x40 | 75 | 54 | 27 | 40 | 60 |
2.1/2x2 | 75x63 | 75 | 55 | 45 | 63 | 84 |
3x1 | 90x32 | 90 | 70 | 25 | 32 | 78 |
3x1.1/4 | 90x40 | 90 | 67.5 | 29 | 40 | 80 |
3x2 | 90x63 | 90 | 63 | 49 | 63 | 76 |
3x2.1/2 | 90x75 | 90 | 69 | 57 | 75 | 71 |
4x1 | 110x32 | 110 | 82 | 23 | 32 | 93 |
4x1.1/4 | 11.x40 | 110 | 82 | 29 | 40 | 94.5 |
4x1.1/2 | 110x50 | 110 | 82 | 34 | 50 | 91 |
4x2 | 110x63 | 110 | 82 | 47 | 63 | 95 |
4x2.1/2 | 110x75 | 110 | 82 | 52 | 75 | 92.5 |
4x3 | 110x90 | 110 | 82 | 78 | 91 | 95 |
6x2 | 160x63 | 1690 | 130 | 44 | 63 | 133 |
6x2.1/2 | 160x75 | 160 | 131 | 56 | 75 | 128 |
6x3 | 160x90 | 160 | 131 | 69 | 90 | 127 |
6x4 | 160x110 | 160 | 131 | 08/05/13 | 110 | 132 |
8x2 | 200x63 | 200 | 163 | 49 | 63 | 198 |
8x3 | 200x90 | 200 | 163 | 71 | 90 | 197 |
8x4 | 200x110 | 200 | 163 | 85 | 110 | 197 |
8x6 | 200x160 | 200 | 163 | 122 | 160 | 198 |
8x7 | 200x180 | 200 | 163 | 139 | 180 | 197 |
9x2 | 225x63 | 225 | 182 | 49 | 63 | 197 |
9x3 | 225x90 | 225 | 182 | 70 | 90 | 196 |
9x4 | 225x110 | 225 | 182 | 85 | 110 | 197 |
9x6 | 225x160 | 225 | 182 | 124 | 160 | 196 |
9x8 | 225x200 | 225 | 181 | 158 | 200 | 197 |
10x2 | 250zx63 | 250 | 200 | 49 | 63 | 196 |
10x3 | 250x90 | 250 | 203 | 71 | 90 | 196 |
10x4 | 250x110 | 250 | 200 | 85 | 110 | 196 |
10x6 | 250x160 | 250 | 201 | 124 | 160 | 196 |
10x8 | 250x200 | 250 | 201 | 153 | 200 | 196 |
12x4 | 315x110 | 315 | 254 | 84 | 110 | 212 |
12x6 | 315x160 | 315 | 257 | 123 | 160 | 212 |
12x8 | 316x200 | 315 | 255 | 158 | 200 | 2152 |
12x10 | 315x250 | 315 | 257 | 197 | 250 | 212 |
Note :
|
