Planomiller Machines

Listing ID #3822594

  • Supply Type Manufacturer, Exporter, Supplier
  • Preferred Buyer Location All over the world

ECHNICAL FEATURES : Duly seasoned alloyed high duty castings Sturdy construction to ensure vibration-free working Ram alignment with taper jib strip Extensive lubrication arrangements Alloy steels....
View More Details
Send Enquiry

Company Information

  • Member Since 10 Years
  • Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

ECHNICAL FEATURES :

  • Duly seasoned alloyed high duty castings
  • Sturdy construction to ensure vibration-free working
  • Ram alignment with taper jib strip
  • Extensive lubrication arrangements
  • Alloy steels shafts
  • All alignments maintained as per geometric alignment test IS : 2310-1963
  • Universal/fixed table with variable automatic feeds on horizontal traverse
  • Expanding ring type clutch drive in all-geared machines to eliminate slippage
  • Graduated tool slide swivelling 90 degrees either way
  • Interchangeability of parts ensured through standardisation and quality control
  • Accuracy and performance guaranteed

STANDARD ACCESSORIES :

  • Swivelling Vice
  • Allen Key Set
  • V-Belts
  • Crank Handle
  • Spanner Set
  • Screw Driver
  • Oil Can
  • Motor Pulley
  • Tool Box
  • Electric Motor & starter with fittings & wirings

EXTRA ACCESSORIES :

  1. Key way cutting attachment
  2. Automatic tool lifting device
  3. Automatic feed to the tool slide
  4. Automatic lubricanting pump
  5. Rapid feed system with control panel


- CAPACITY 12" 18" 24" 30" 36" 42"
Length of Ram Stroke 305 mm 457 mm 610 mm 762 mm 915 mm 1070 mm
Length of Ram 711 991 1232 1474 1651 2108
Length of Width of Ram bearing 724 x 203 686 x 273 867 x 30 975 x 325 1130 x 300 1600 x 330
Max. & Min. distance from Table of Ram 257 x 41 381 x 83 508 x 76 610 x 102 525 x 102 530 x 102
B- TABLE
Working Surface of Table 305 x 228 457 x 305 610 x 356 762 x 406 915 x 457 196 x 533
Max. Table Travel Horizontal 330 483 635 787 860 1050
Max. Table Travel Vertical 140 305 406 483 525 455
Angular Movement of Table on either sides 60 L 60 R 60 L 60 R 60 L 60 R 60 L 60 R 60 L 60 R 60 L 60 R
C - TOOL HEAD
(Max. Vertical Traval of Tool Slide) 140 152 204 203 225 300
Maximum Swivel of Tool Head 60 L 60 R 60 L 60 R 60 L 60 R 60 L 60 R 60 L 60 R 60 L 60 R
D - BASE
Length of Width of Base 940 x 483 1346 x 502 1676 x 610 1829 x 660 1980 x 660 2286 x 762
E - SPEEDS & FEEDS
Dia of Clutch Pulley 235 311 311 311 380 380
Range of Ram Speeds 3 4 4 4 4 4
Stroke per minute 30, 60, 90 16, 32, 64, 96 12, 24, 48,72 8,16, 32, 48 10, 20, 30, 50 8, 16, 32, 48
Dia of Motor Pulley 51 70 70 76 88 88
Range of Table Feed per Stroke of Ram 0.299 0.220 0.229 0.229 0-22 to 0-88 150 to 600
Range of Tool Head Feed Hand Feed Hand Feed Hand Feed Hand Feed Hand Feed Hand Feed
Automatic Tool Head Feed & Tool Lifting On Order On Order On Order On Order On Order On Order
F- DRIVE ELECTRICAL EQUIPMENTS
Power Supply 1 HP (75kw) 2 HP (1.5kw) 15 HP (12.2kw) 5 HP (3.75kw) 7.5 HP (5kw) 10 HP (7.5kw)
Speed RPM 1440 RPM 1440 RPM 1440 RPM 960 RPM 960 RPM 960 RPM
V. Belt Section B-55 B-55 B-55 B-58 B-70 B-75
Main Switch Starter (Push Button Type) 3.5 AMP 3.5 AMP 5 AMP 5 AMP 5 AMP 3.5 AMP
G - OVERALL DIMENSIONS & WEIGHT
Length 1219 1580 1981 2150 2500 2875
Width 762 948 1092 1219 1350 1500
Height 1371 1400 1600 1550 1700 1850
Weight (Approx) 700 Kgs 1500 Kgs 2000Kgs 2700Kgs 3500 Kgs 4000 Kgs
