Phosphorous Bronze Ingot, Grade : ASTM, Grade 5

Phosphorous Bronze Ingot, Grade : ASTM, Grade 5

Listing ID #6885968

850 - 1,350 / Kilogram

Get Latest Price

MOQ 300.00 Kilogram
Size20x3inch, 25x4inch, 30x5inch, 35x6inxh, 40x7inch, ASTM, BS, As Per IS:1458-1985
TypeBronze Ingot, Phosphorous Bronze Alloys Ingots As Per IS:1458-1985 Reaffirmed 2006 & IS:28-1985 Or Latest
MaterialBronze
ShapeRectengular, Square, Shape Of Plates
Supply Type Exporter, Supplier, Importer
Preferred Buyer Location All over the world

View More Details

Send Enquiry

Product Details

Size 20x3inch, 25x4inch, 30x5inch, 35x6inxh, 40x7inch, ASTM, BS, As Per IS:1458-1985
Type Bronze Ingot, Phosphorous Bronze Alloys Ingots As Per IS:1458-1985 Reaffirmed 2006 & IS:28-1985 Or Latest
Material Bronze
Shape Rectengular, Square, Shape Of Plates
Weight 1-100kg, 10Kg - 12Kg
Grade ASTM, BS, Grade 5
Color Brown, Golden, Metallic, Red, Reddish Orange Colour
Purity Nickel & Phosphorous
Condition New, Melt & Cast In Moulds As Per Required Size; Its Used For Remelting To Manufacture Castings
Surface Finishing Non Polished, Dross & Other Harmful Contaminations
Country of Origin India
Brand Name Our Own Brand
Application The Ingots Prapared Are Remelted & Alloyed To Produce Industrial Castings & Other Products
Dimension As Per Customer's Required Drawings,
Chemical Composition As Per Grade 1, Grade 2, Grade 3, Grade 4, Grade 5.
Warranty Within the Range of Specifications
Weight of Each Ingot 12Kg to 13Kg & 15Kg to 17Kg

Phosphorous Bronze Ingots cast as per IS:1458-1985 Reaffirmed 2006, Class -1, IS:28-1985 Or Latest Specifications having Grade -1, Grade -2, Grade – 3, Grade – 4, Grade – 5. Chemically they represent the following compositions as follows: -

Constituent	IS:1458-1985 Reaffirmed 2006	Constituent	IS:28-1985 Or Latest Specifications
	Class 1		Grade 1	Grade 2	Grade 3	Grade 4	Grade 5
Tin	6.0 – 8.0	Tin	6.0 – 8.0	10.0 Min	6.5 – 8.5	9.0 – 11.0	11.0 – 13.1
Lead	0.5 Max	Phosphorous	0.30 – 0.50	0.50 Min	0.30 Min	0.15 Max	0.15 Min
Zinc	0.5 Max	Lead	0.25 Max	0.25 Max	2.0 – 5.0	0.25 Max	0.50 Max
Phosphorous	0.4- 0.6	Zinc	0.50 Max	0.05 Max	2.0 Max.	0.05 Max	0.30 Max
Iron	0.3 Max	Nickel	0.70 Max	0.10 Max	1.0 Max	0.25 Max	0.50 Max
Antimony	0.1 Max	Iron	0.30 Max	0.10 Max			0.15 Max
Iron & Antimony		Aluminium	0.01 Max	0.01 Max			0.01 Max
Aluminium	0.01 Max	Antimony	0.10 Max
Total of Other Elements including Iron & Antimony	0.6 Max	Silicon	0.02 Max	0.02 Max			0.02 Max
Total of Other Elements including Iron & Antimony	0.6 Max	Total Impurities	1.20 Max	0.60 Max	0.50 Max	0.80 Max	0.20 Max
Copper Plus Incidental Nickel	Remainder	Copper	Remainder	Remainder	Remainder	Remainder	Remainder

Additional Information

Payment Terms L/C, T/T
Port of Dispatch Haldia Port, Khidderpore Port.
Packaging Details They are packed in Gunny Bags with Seal and placed inside Wooden Cartoons Or Loaded In Containers.
Delivery Time As Per Order

Interested in this product? Ask for more details & Latest Price from seller

Send Enquiry

Product Images

Company Details

Being in the industry for more than 4 decades, we R.J.Metal Industries is a Kolkata (West Bengal, India) based organization that is engrossed in offering the finest quality foundry products to our esteemed customers. We are the topmost manufacturer and supplier of a wide range of foundry products such as Phosphorous Bronze Ingots, Phosphorous Bronze Rods, Phosphorous Bronze Bush, Phosphorous Bronze Flanges, Phosphorous Bronze Split Bush, Phosphorous Bronze Plates, Brass Plates, White Metal Ingots, Copper Magnesium Alloy Ingots, Silicon Copper Alloy Ingots, Phosphorus Copper Ingots, Lead Tin Bronze Ingot And Castings, Aluminium Alloy Ingot Casting, LM Series Aluminium Ingot, Aluminium Bronze Ingots And Castings, High Tensile Brass Ingots And Castings, Tin Bronze Ingots & Castings, Copper Silicon Alloys Ingots etc. All these products can be obtained at cost-effective prices worldwide, primarily in the Indian Subcontinent, United Arab Emirates, Nepal, Bhutan, and Bangladesh.

Our Firm was established in the year 1979 under the entrepreneurship of Mr. Manaranjan Das who is the Technical Head. He is a Metallurgical Engineer with a B. E. in Metallurgy and has over 40 Years of Experience in the field. It was under the tutelage of our Founder, that our Firm succeeded in establishing a well-equipped facility for Melting Non-Ferrous Metals and producing Sophisticated Products as per Current Market Demands with Efficiency & Moral Integrity.

R.J.Metal Industries is supported by a skilled labour force who are chiefly dedicated towards their work and it is their honesty & efficiency that have played a major role in making us what we are now. Their hard work and consistency with diligence & quest for knowledge and improvement have been key to our success in the competitive market. Defying all infirmities and hard times, they are wholeheartedly devoted towards their work for further development in knowledge for producing sound quality castings and products.

Our Firm extends over an industrial area of 7500 Square Feet which houses our In House Office, Melting Shop, Go-Down for Storing Incoming Raw Materials & for Finished Materials. It also includes our machine shop where castings are machined and sectioned as per drawings. Besides that, we have a well-equipped Pollution Control System. While much of our raw materials are available in the local market, we are also importing metals from foreign countries. Our Firm is accredited by ISO : 9001-2015 Standards. Our foundry also customizes products by outsourcing for better material properties, sophisticated needs and applications.
