Temperature coefficient≤ 0.05 % FSR/10 K , measuring span
≤ 0.05 % FSR/10 K , zero point
Max. measuring error± 0.1 % FSR , up to 2:1 turndown ratio,
± 0.25 % FSR , up to 4:1 turndown ratio
Including zero-point and span error, nonlinearity (by terminal base line), hysteresis and non-repeatability (EN 61298-2)
For turndown, multiply this value by the ap
Temperature coefficient≤ 0.05 % FSR/10 K , measuring span
≤ 0.05 % FSR/10 K , zero point
Max. turndown ratio10:01:00 AM
Pressure typeAbsolute
Relative (gauged)
Power-up time< 10 s
Sample time≤ 0.3 s
Long term stability≤ 0.1 % FSR/a , IEC 770 6.3.2
Explosion protectionATEX II 1D Ex ia IIIC T100 °C Da,
ATEX II 1G Ex ia IIC T5,
ATEX II 3G Ex nA IIC T5
Compensated temperature range-40 … 85 °C
Max. measuring span69 bar
Standard error of measurement (BFSL)± 0.04 % FSR , up to 2:1 turndown ratio,
± 0.1 % FSR , up to 4:1 turndown ratio,
Including non-linearity, hysteresis and non-repeatability according BFSL
For turndown, multiply this value by the applied turndown ratio
Max. measuring error± 0.1 % FSR , up to 2:1 turndown ratio,
± 0.25 % FSR , up to 4:1 turndown ratio
Including zero-point and span error, nonlinearity (by terminal base line), hysteresis and non-repeatability (EN 61298-2)
For turndown, multiply this value by the ap
Rise time (10 ... 90 %)≤ 0.3 s
Min. measuring span0.05 bar
