Semi Automatic Oil Extraction Machine, for Multi Oilseeds, Model Number : GOYUM 150, GOYUM 150

Listing ID #6091152

Get Latest Price

MOQ 1 piece
Brand NameGOYUM
Operating TypeSemi Automatic
UsageMulti Oilseeds
Model NumberGOYUM 150
Supply Type Exporter, Supplier
Preferred Buyer Location All over the world

View More Details

Product Details

Brand Name GOYUM
Operating Type Semi Automatic
Usage Multi Oilseeds
Model Number GOYUM 150
Length 8\'6\
Kettle Motor For 3 Stage: 3 Phase, 5 HP, 1440 RPM, For 4 Stage: 3 Phase, 7.5 HP, 1440 RPM
Chamber Size Dia 7.5” X Dia 6.5” X 45” Long
Weight 4800 kgs (With Three Stage Kettle), 5500 Kgs (With Four Stage Kettle)
Expeller Motor 3 Phase, 40 HP, 1440 RPM
Height 13' (With Four Stage kettle), 11'5
Crushing Capacity 15 – 17 Ton in 24 Hours

Oil Extraction Machine is used to extract oil from various types of edible oil seeds as well as non-edible oil seeds & nuts.

Features:

Bodies and Base	Fabricated from Mild steel
Gearbox	Double Reduction Gearbox with Helical Gears of Cast Steel and Pinions of Alloy Steel.
Chamber	Steel Casting of Four Sections. Horizontally fitted Size: Ø 7.5” X Ø 6.5” X 45” Long.
Worm Assembly	Hard Faced along with Discharge Ring and Compression Ring
Main Worm Shaft	Can be withdrawn out without Disturbing the Gear Box.
Kettle	3 or 4 stages with Steam Jackets of Ø 48” for efficient cooking of Seed. Pipe Fitting Contains Safety Valve, Steam Spray Pipe, Pressure Gauge, Steam Valves & Steam Traps.
Cake Thickness	Can be Adjusted on Running Machine.
Crammer Shaft	For extra Cramming of the Seed or Cake in the Feed Body.
Oil & Oil Cake	Superior Quality
Maintenance	Minimum
Crushing Capacity	Differs with the density of oilseeds & nuts and quantity of oil in it.

Technical Specification

Model	Capacity	Motor Power	Length	Breadth	Height
GOYUM 150	15 – 20 TPD*	3 Phase 40 HP for Expeller 3 Phase 7.5 HP for Kettle	8.66 ft	6.33 ft	12.16 ft

*(TPD stand for Ton Per Day (in 24 Hours) of Oilseed Crushing Capacity. Further crushing capacity may differ with the density of oilseeds & nuts and quantity of oil in it.)

Additional Information

Port of Dispatch Mumbai / Mundra
Packaging Details Wrapped in polythene sheet & then Packed in Quality Wooden Box (For Export)
Delivery Time 15 – 20 days, but confirmed delivery time will be provided at the time of confirmation.

Interested in this product? Ask for more details & Latest Price from seller

Send Enquiry

Company Details

GOYUM SCREW PRESS is a leading Project Engineering Company established in 1971 and now a prominent name in the Oilseed's Oil Extraction Plant, Edible & Non-Edible Oil Processing Plants & Allied Industry.
We are a Family Owned Company and Pioneer in Planning, Engineering, Manufacturing and Installation & Commissioning for Automatic Oil Mill Plant, Palm Kernel Oil Extraction Plant, Solvent Extraction Plant, Edible Oil Refinery Plant, Fish, Poultry & Animal Feed Plant, Oleo chemical Plant Flour Mill Plant, Rice Mill Machinery, EFB, MSW, Plastic & Industrial Shredder Used Engine Oil Re-Refining Plant, Waste Tyre Recycling Plant, Solar PV Solutions Water & Waste Water Treatment Plant, Cosmetic Plant, Food Processing Solutions on Turnkey Basis Worldwide.
Further, we also undertake the expansion of the existing plants with modern technologies.
We at GOYUM have a state-of-the-art manufacturing facilities spread in 27,000 Sq.m. covering production area for Fabrication, Welding, Machining, Assembly, Painting, Packaging, etc. In strive to deliver our valued customer best product, we keep on continuously improving our manufacturing system.
The plants offered by GOYUM are robust, flexible, reliable and efficient. These plants are based on the commercially proven technologies, which are not only energy efficient & environment friendly, but also cost effective.
We have supplied more than 750 projects on Turnkey basis which are running successfully in 6 Continents covering more than 60 countries.
The GOYUM is backed by a strong leadership, dedicated workforce and updated technology.
