Motorised Bench Type Load Frame

Motorised Bench Type Load Frame :
Alpha Chem is manufactures,exporter & suppliers Motorised Bench Type Load Frame.
Motorised Bench Type Load Frame : This is a portable load frame which can easily be kept on Laboratory bench. Thus it is very convenient to the user to conduct tests. A motorized screw jack is fixed at the base to which are fixed two vertical pillars which can be easily dismantled.
A circular platen of 150mm diameter is fixed to the lead screw and loading and unloading is effected by upward/downward movement of the lead screw using a forward/reverse switch. The cross head is adjustable at any desired height and carries an adapter for Proving Ring. An adjustable dial gauge bracket is provided on one of the pillars . The rate of strain is constant 1.25mm/min. Operates on 230 Volts AC.
