Contact SupplierOur company is actively involved in the manufacture of the CNC Turning Centers (Model No. FBL 350). The component used as well as the subsequent quality of the CNC Turning Center is very good and it complies with the national and international quality parameters. Features
Technical Specifications
Capacity | ||
Max. Turning DIA. | 500 mm | |
Max. Turning Length | 1000/1500 mm | |
Swing Over bed | 600 mm | |
STD. Turning Dia. | 350 mm | |
Main Spindle | ||
Spindle Nose | A2-8 | |
Bore Through Spindle | 75 mm | |
Bar capacity | 62 mm | |
Chuck Size | 315 mm | |
Frong Bearing Bore | 100 mm | |
Spindle Drive | ||
Spindle motor Power Cont./15 Min. Rating | 15 HP | |
Speed Range (RPM) | 1000 | |
Axes Slides | ||
X Axis Stroke | 350 mm | |
Z Axis Stroke | 1050 / 1550 mm | |
Rapid Traverse : X Axis | 15 M/Min. | |
X-Axis Guide ways | LM | |
Rapid Traverse : Z Axis | 15 M/Min. | |
Z-Axis Guide ways | LM | |
Tail Stoke | ||
Quill Diameter | 100 | |
Quill Stroke | 100 | |
Taper in Quill | MT 5 | |
Turret | Â | |
Turret Type | ELE. Mechanical | |
No. of Stations | 4/8 | |
Max. Boring Bar Dia. | 32/40 | |
Tool cross section | 25 mm | |
Accuracy | Â | |
Position Accuracy | 0.015 mm | |
Repeatability | ± 0.003 mm | |
Machine Dimensions | Â | |
Dimension (LxBxH) | 3500 x 1950 x 1850 | |
Weight (Approx.) | 5050 kg. |
