Contact SupplierWe are offering medical microscope
amtech india’s medical microscope md-07 features :
body: sturdy heavy bodywith hinged type horse shoe base inclinatiion inclination upto 90’ with safety stopper for slides and having precisely graduated slowmotion reading upto 0.002mm.
Tube: standard length 160mm with triple revolving nosepiese with stopclick .
Mechanics : separate coarse and fine focus knobs .
Stage: fixed stage size 120 * 120 mm carrying a detachable mechanical stagewith vernier reading and specimen mover handwheels for moving the specimen .
Illumination: by abbe condensor of n.a 1.2 and iris diaphragm with filter holder movable by knob on lower left side . Detachable 50mm plano-concave mirror in fork .
Objectives : parafocal achromatic objectives 10x, 40x/45x s.l, 100x (oil immersion) .
Eyepieces : widefield 10x, huygenian 5x .
Standard accessories : filter, dust cover, cleaning cloth, operating manual, immersion oil .
Available in styrofoam packing or wooden cabinet or both .
