Contact SupplierThe wide range of products is a result of intense quality analysis of raw materials at the initial stages of production. With stern checking, the products are examined with utmost precision. With the advancement of technology, we have also adopted a secure payment procedure that is easy to use and featured with multiple options.
Advantages
Specifications | Details |
---|---|
Shifiting mechanism | Rack and pinion |
Max load capacity | 1000kgs/12 persons |
Lifting Speed | 28 Mtr min. |
Cage size(mm) | 2000(L)*1300(W)*2100(H) |
Mast Section Size | 700*700*1507(pipe 76) |
Max lifting Height | 100 Mtr |
power | 3*10Hp(7.5Kw) |
Gear Box | Planetory |
Rack & Pinion | Module 8 |
Door | 3 |
Guide | 27(24+3) |
Controller | PLC Base |
VFD | 20Hp(make-fuji) |
Main Switch | Rotary Type |
Alarm | Safety Brake Active/ Manual |
Light | YES (CFL) |
Fan | Yes |
Power Cable | Rubber Coated |
Electrical Interlock | Yes by Limit Switch |
Floor Selection | Yes |
Operation Mode | Auto and manual |
Specifications | Details |
---|---|
Door interlock | By limit Switch |
Upper Limit | 3 Nos. |
Lower Limit | 3 Nos. |
Cage Size (mm) | 2000(L)*1300(W)*2100(H) |
Barricadding at Base | YES |
Fall Safe Device | Yes (1 Nos.) |
Emergency Stop | Yes (2 Nos.) |
