Contact SupplierHydraulic Dock Leveller and Pit Technical Data | ||||
---|---|---|---|---|
Dimensions | Platform Length L/(±2) | 2000mm | 2500mm | 2210mm |
Platform Width W/(±2) | 2000mm | 2000mm | 1830mm or 2130mm | |
Platform Height H/(±2) | 600mm | 600mm | 500mm | |
Required size of foundation pit | Corresponding foundation pit length L1(±2) | 2000mm | 2500mm | 2210mm |
Corresponding foundation pit width W1(±2) | 2050mm | 2050mm | 1880mm or 2180mm | |
Corresponding foundation pit width H1(±2) | 615mm | 615mm | 515mm | |
Parameter information | Upper working scope WB(limit) | 725mm | 750mm | 745mm |
Lower working scope W0(limit) | 380mm | 375mm | 225mm | |
Clapper material:tear plate | Basic thickness 14mm,double 5 degree bending | |||
Surface | Black advanced expoxy resin finish,long effect anti-corrosion protection | |||
Power consumption | ≤1.5Kw | |||
Operating temperature | -35oC~ ~+50oC |
