This is an ophthalmic instrument, used for diagnosing imbalance of eye muscles and treating them by orthoptic methods.
All the standard measurements and treatments are possible on this instrument including assessment of the angle alpha, the objective angle, abnormal retina correspondence, cyclophoria, hyperphoria and horizontal vertical vergences. An automatic flashing unit allows each eye to be stimulated alternately or simultaneously.
Manual flashing switches and independent dimming rheostats are provided as standard. After images are achieved by using high intensity halogen light sources and condensing systems. A pair of removable haidinger's brushes motor units are included, which allows the user to employ pleoptic techniques to assess and treat eccentric fixation and abnormal retinal correspondence.
movement of optical tubes:
horizontal : adduction + 50deg, abduction - 40 deg
vertical : hyper 30 deg, hypo 30 deg
torsional : incyclo 20 deg, excyclo 20 deg
slide illumination:-
by rheostat controlled 6v lamp for each slide. After image illumination by 6v lamp
auto flashing:-
auto flashing of slide illumination either simultaneously or alternatively in rapid & variable modes
mode & mode selection:
five modes of slide illumination namely normal, flashing right, flashing left, flashing r+ l & auto flashing can be selected by a single selector knob.
Dimensions:-
longitudinal: 30.3 cms
lateral: 25.5 cms
vertical: 36.5 cms
weight: 20 kgs
power supply: 220 v ac 110v
standard accessories:-
a set of slides containing 10 pairs, one power cord, one dust cover
optional accessories:-
instrument table: manual or motorized
haidinger brush attachment.
