Contact SupplierModel | STM-60 | STM-100 | FST-100 | FST-200 | FST-500 |
Maximum Capacity (kN) | 60 | 100 | 100 | 200 | 500 |
1st Range (kN) | 0 - 60 | 0 - 100 | 0 - 100 | 0 - 200 | 0 - 500 |
Least count (kN) | 0.1 | 0.2 | 0.2 | 0.4 | 1.0 |
2nd Range (kN) | 0 - 30 | 0 - 50 | 0 - 50 | 0 - 100 | 0 - 250 |
Least count (kN) | 0.05 | 0.1 | 0.1 | 0.2 | 0.5 |
3rd Range (kN) | 0 - 18 | 0 - 25 | 0 - 25 | 0 - 40 | 0 - 100 |
Least count (kN) | 0.03 | 0.05 | 0.05 | 0.08 | 0.2 |
Table size (mm) | - | - | 250 x 2400 | 400 x 2400 | 460 x 2650 |
Clearance for-compression test (mm) | 0 - 1250 | 0 - 1250 | 0 - 400 | 0 - 650 | 0 - 750 |
Distance between trolleys (adjustable) (mm) | - | - | 500 - 2150 | 650 - 2150 | 850 - 2300 |
Ram stroke (mm) | 200 | 200 | 250 | 250 | 300 |
Straining speed at no load (mm/min.) | 0 - 200 | 0 - 125 | 0 - 250 | 0 - 150 | 0 - 100 |
Pair of compression plates dia (mm) | 350 | 350 | 250 | 400 | 450 |
Least count of deflection Measurement with DRO (mm) | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 |
Clearance between columns (mm) | 450 | 450 | - | - | - |
Width of recorder chart (mm) | 150 | 150 | 150 | 150 | 150 |
Connected load (HP) | 1.5 | 1.5 | 1.5 | 2.0 | 3.0 |
Voltage (V) | 440 | 440 | 440 | 440 | 440 |
Phase (Ph) | 3 | 3 | 3 | 3 | 3 |
