Contact Supplier1.designed according the high request and the reliable function, the operation of the machine is humanization, can accomplish the setting, revision, implement, replacing and memories function in a shot time, and display with a exact data.
2.all the drive rollers adopted high quality steel materials, hard chromium plating and the surface treated by lapping finish.
3.the drive gears adopt high quality alloy steel, after heat treatment and lapping finish.
4.lubricate oil automatic balance device, keep the equal oil level equal in each unit.
5.the machine adopt plc control, with “automatic zero return” and ”emories” function.
6.use sun feeder for feed the cardboard.
7.customer can chose use steel anilox roller or ceramic roller, the lines of the anilox roller ac so can be chosed accord the customer use.
parameter | unit | SYKM950-1800 | SYKM950-2000 | SYKM950-2200 | SYKM4215-2200 | SYKM4215-2400 |
---|---|---|---|---|---|---|
Max. machinery speed | Pcs/min | 180 | 180 | 180 | 150 | 150 |
Economic printing speed | Pcs/min | 150 | 150 | 150 | 130 | 130 |
Max. size of paperboard | mm | 950×2000 | 950×2200 | 950×2400 | 950×2400 | 950×2600 |
Min. size of paperboard | mm | 260×600 | 260×600 | 260×600 | 260×600 | 260×600 |
Min. space ofslotting(Obverse knife) | mm | 160x160x160x160 | 160x160x160x160 | 160x160x160x160 | 160x160x160x160 | 160x160x160x160 |
Min. space ofslotting(Reverse knife) | mm | 280x80x280x80 | 280x80x280x80 | 280x80x280x80 | 280x80x280x80 | 280x80x280x80 |
Max. depth of slot | mm | 240 | 240 | 240 | 300 | 300 |
Skip feed size | mm | 110×2000 | 1100×2200 | 1100×2400 | 1500×2400 | 1500×2600 |
Max. printing area | mm | 950×1800 | 950×2000 | 950×2200 | 1250×2200 | 1250×2400 |
Thickness of standard printing plate | mm | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 |
