LC Connector

LC Connector

Listing ID #6242528

Get Latest Price
  • MOQ 1 Piece
  • Return Loss>50dB (PC) >65dB(APC)
  • Repeatability<0.1dB
  • Insertion Loss<0.20dB
  • Interchangeability<0.2dB
  • Supply Type Exporter, Supplier, Retailer, Importer, Trader
  • Preferred Buyer Location All over the world
View More Details
Send Enquiry

Company Information

Projexon softech PVT LTD verified-icon
Badlapur West, Mumbai, Maharashtra
View Number
  • Member Since 2 Years
  • Nature of Business Manufacturer
  • GST No. 27AAKCP0476C1ZH

Ask for more detail from the seller

Contact Supplier
View Company Details

Product Details no_img_icon

  • Return Loss >50dB (PC) >65dB(APC)
  • Brand Name Projexon
  • Operating Temperature –40 Degree C to +85 Degree C
  • Repeatability <0.1dB
  • Durability Plug & Unplug 1000 times
  • Insertion Loss <0.20dB
  • Diameter 0.9 mm, 2 mm, 3 mm (UPC/APC)
  • Interchangeability <0.2dB

Features :

  • High return loss.
  • Low insertion loss.
  • Telcordia style boots.
  • Compliance with TIA/IEA, IEC, Rohs.
  • Entire products are 100% RoHS Compliant.


Applications :

  • CATV, Metro, LANs.
  • Active device termination.
  • Telecommunication networks.
  • Industrial, medical & military.


Specifications

  Single mode Multimode
Diameter 0.9 mm, 2 mm, 3 mm (UPC/APC) 0.9 mm, 2 mm, 3 mm (UPC)
Insertion loss <0.20dB <0.2 dB
Return loss >50dB (PC) >65dB(APC) >20dB
Repeatability <0.1dB -
Interchangeability <0.2dB -
Durability Plug & Unplug 1000 times -
Operating Temperature –40 °C to +85 °C –40 °C to +85 °C
Interested in this product? Ask for more details & Latest Price from seller
Send Enquiry

Company Details close-icon

Projexon is manufacturing of optical fiber patch cord, and supply of optical fiber connector, cables.
  • Nature of Business Manufacturer / Exporter / Supplier / Retailer / Importer / Trader
  • Number of Employees Below 20
  • Year of Establishment 2018
