·         Inner Chamber: MS with 1.6mm Thickness.

·         Outer Chamber: Made up of MS 1.2mm Thickness.

·         Outer Chamber Color: Industrial Blue (Or Optional)

·         Doors: 2 Numbers of Heavy Duty Doors opening outside.

·         Door Lock: Heavy Duty Steering Type.

·         Motor: 1 Numbers1 HP (National Products make) 1440 rpm On top of the Oven with strong shaft and fan blades to circulate Air inside the chamber.

·         Blower: MS Impeller with 18” length. ON/OFF Switch with 9 amp contactor with overload switch. 4 Numbers of amp meter.

·         Heater: 12 Nos (1.5KV Each) of SS 304Tubular heater.

·         Maximum Temp: Up to 200° temperature.

·         Working Temp: Up to 150° temperature.

·         Temp. Accuracy: +/- 1 degree Celsius.

·         Insulation: 75mm thick Rockwool (60/m² density) insulation between two walls.

·         Rating: 18KW.

·         MCB: 2 Nos of 4 poles MCB (L&T make) 63 amp.  4 Numbers 32 amp MCB for Heater ON/OFF

·         Air Vents: 4 Numbers Hot Air Outlet on Top of the Oven

·         Supply: 3 Phase

·         Power Supply: 440Volts, 50Hz.

·         Inner Chamber: MS with 1.6mm Thickness.

·         Outer Chamber: Made up of MS 1.2mm Thickness.

·         Outer Chamber Color: Industrial Blue (Or Optional)

·         Doors: 2 Numbers of Heavy Duty Doors opening outside.

·         Door Lock: Heavy Duty Steering Type.

·         Motor: 1 Numbers1 HP (National Products make) 1440 rpm On top of the Oven with strong shaft and fan blades to circulate Air inside the chamber.

·         Blower: MS Impeller with 18” length. ON/OFF Switch with 9 amp contactor with overload switch. 4 Numbers of amp meter.

·         Heater: 12 Nos (1.5KV Each) of SS 304Tubular heater.

·         Maximum Temp: Up to 200° temperature.

·         Working Temp: Up to 150° temperature.

·         Temp. Accuracy: +/- 1 degree Celsius.

·         Insulation: 75mm thick Rockwool (60/m² density) insulation between two walls.

·         Rating: 18KW.

·         MCB: 2 Nos of 4 poles MCB (L&T make) 63 amp.  4 Numbers 32 amp MCB for Heater ON/OFF

·         Air Vents: 4 Numbers Hot Air Outlet on Top of the Oven

·         Supply: 3 Phase

·         Power Supply: 440Volts, 50Hz.
