Operation interface 8.4” tft true color lcd screen
wavelength shr handle: 610-950nm
e-light handle: 430530640-1200nm(standard)
480nm560nm590nm690nm750 nm-1200nm(optional)
working mode shr+normal e-light(sr,ar,pr,wr)
spot size 10*50 mm²(shr handle);12*30 or 15*50 mm²(e-light handle)
shropt frequency 1-10hz adjustable ( 1 second emit 1-10 flashes)
pulse width 1-50ms
pulse amount 1-6
energy 1-50j cm²
handle number 1pc or 2 pcs optional
shr power 3000w
rf power 300
fans 7pc
radiation 2 big car used radiation
net weight 45kg.
