Jumbo Bag Loading Station

Listing ID #3958356

  • Supply Type Manufacturer, Exporter, Supplier
  • Preferred Buyer Location All over the world

Jumbo Bag Fillers insure fast, dust free and precise filling of Jumbo Bags. Available in a variety of configurations this ruggedly constructed filler allows its operators to easily insert, fill....
View More Details
Send Enquiry

Company Information

  • Member Since 7 Years
  • Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

Jumbo Bag Fillers insure fast, dust free and precise filling of Jumbo Bags. Available in a variety of configurations this ruggedly constructed filler allows its operators to easily insert, fill and remove bags. From simple volumetric filling to calibrated weighing, the AL!X - Jumbo Bag Filler is the unit that is custom built for your application.
AL!X - has designed a number of jumbo bag loading frames for different applications and will aggressively respond to all bulk bag loading opportunities. The frames from AL!X are simple, sturdy frames of square tubular construction with four legs and permitting a great number of loading options, including the supports for these. A simple bungee cord bag neck damp offers a major advantage in being able to seal any bag neck from 13 inch diameter to 24 inch diameter without changing the bag neck spout. An inflatable cuff, which is common on competitive units, is offered as an option. The disadvantage of this device is that a single size cannot accommodate a wide range of bag necks. The versatile and simple single venturi power unit with venturi discharge provides a source of low pressure air for bag inflation. A filter for the air displaced from the bag is standard. Adjustment for different size bags is accomplished by raising or lowering the deck of the weigh frame.
  • Heavy duty square tubular frame with welded top section and bolted legs.
  • Internal weigh frame with four load

Description :
  • Sturdy welded tubular steel frame.
  • One piece fill spout.
  • Inflatable inlet spout seal with regulator.
  • Vibrating platform for consistent filling.
  • Adjustable height bag loop supports.
  • Adjustable width bag loop supports.
  • Dust connection vent.
  • Pallet stops.
  • Enamel Paint.
  • Custom configurations available.

Optional Items :
  • Adjustable height frame.
  • Load cells with isolation pads..
  • Partial or fully automated operation.
  • Bag inflation system with butterfly valves.
  • Inline air filter / regulator with local shut off valve.
  • Dust collection system.
  • Pneumatic vibrator.
  • Inlet flow control valve.
  • Epoxy Paint.

Contact / Frame Materials :
  • Carbon Steel
  • 304 Stainless Steel
  • 316 Stainless Steel

Motors :
  • Standard: 230-460v TENV motor enclosure
  • Optional: Special motor voltages on request / Pneumatic


Company Details close-icon

We, at ALIX, are proud to introduce ourselves as one of the top-notch companies holding a field of expertise in manufacturing & exporting finest quality machines.
ALIX automation system specialises in design, engineering & mfg. of cGMP grade mehcanical pneumatic material handling and ingredient processing system for Pharma, Food, Beverages, Chemical & Paint industries. The equipment manufactured by 'ALIX' are for conveying, storing, measuring, milling, screening, mixing & blending of dry materials.
We also expertising in design and manufacture of Centralised Dust Collection Systems and components for Bulk Solid handling systems.
The company offers state of the art Standard Model/ GMP Model with the option for fully automatic PLC (Programmable Logic Controls) for various process equipment's, designed to suit a specific and process as required by the clients product. We have suitable design of our products which are globally accepted, advanced international technology, steady performance, superior quality and best services. Our customer should see us as a professional partner & supplier.
At the ALIX automation system the efficient and academically team spares no stone unturned, to be the best in custom build engineering by combining state-of- the- Art design and technology. The company is committed to ensure that no trouble being spared to see that every user of companies product is satisfied with its equipment.
This products are of proven performance and can be seen in use to small scale industries, top loading Indian Comapanies and Multinationals. The products are also exported to various African, Gulf, Middle East & European etc. countries both directly and also through third party exports.
