Jet Table Blister Pack Machine

Listing ID #4281712

Get Latest Price

Supply Type Manufacturer, Exporter, Supplier
Preferred Buyer Location All over the world

Salient Features :- Fully automatic, system with contnuous operation cycle mechanism for efficient packing Automatic synchronised starwheel system sets harmony with blister formation and ensures....

View More Details

Send Enquiry

Product Details

Salient Features :-

Fully automatic, system with contnuous operation cycle mechanism for efficient packing
Automatic synchronised starwheel system sets harmony with blister formation and ensures smooth feeding.
A comparatively lenthy 'guide track' for rigid inspection for missing blisters, if any.
Crease proof sealing pattern to eliminate capillary formation of foil on sealing.
contact heating system with pneumatic actuation allows blister forming with even heating and save wastage of PVC after every stoppage.
Specially designed ergonomic and aesthetic partially electronic control panel board protects electrical operational components.

Output :-

Strokes per minute(maximum) :40 - 50 strokes
(Size and No. of packs depend on selection of change parts,products to be packed and operaters skills)

Power Requirement :-

(415v ,3 phase,50Hz.,A.C.Electric supply if difrent please specify voltage req)

Dimension in mm:-

L x B x H 3020x680x2084

Packagable Products :-

Glass ampouies up to 10ml.and Glass/plastic vials upto 10ml.Droppers,Syringes,Cannulas etc.,can be packed with manual feeding.

Packagable Materials BASE FILM :-

Opaque, transparent or coloured thermoformable and non-toxic PVC.

LIDDING MATERIAL :-

: inium foil with heat -sealed lacquer or Glassine paper foil.
: Optinal Facilities (available on prior intimation)
- In - line scoring unit for dispersing of blisters into twos.
- Thermoforming of manufacturer's/product's name
- Printing registration of control system
- Combination packing facility.


PVC Base Film	Max width	212 mm
	Thickness	0.35 to 0.45 mm
	Max Reel dia	440 mm
Aluminum foil	Max width	404 mm
	Thickness	0.02 to 0.03 mm
	Max Roll dia	210 mm

Forming Area	Minimum	109 x 140 mm

Pack Length(max)		200 mm

Pack Width(max)		150 mm


Forming Depth		27 mm
