TECHNICAL SPECIFICATIONS

Capacity /Rating : 1 to 10KVA

Input Voltage : 230 V (1 phase, 50 Hz).

                                    Output Voltage : 230 V (1 Phase, 50 Hz).

Conductor : Super Electrolytic Copper

Core : CRGO M-4, Low Losses Lamination

Insulation : Class F

Regulation : +/- 5%

Cooling : Dry Type, Natural Air Cooled

Temperature : 50 Deg. C (above ambient)

Duty Cycle & use : 24 x 7 Continuous, Indoor

C.M.N.R. : 100 db

Load Regulation : Better than 3.5%

Insulation resistance : more than 5 Mega Ohms

Dielectric Strength : 2500V AC fro 60 Sec

Leakage Current ` : Less than 50µA

Efficiency : 97%

Reference Standard : IS 2026
