Industrial Wiring Cable

Industrial Wiring Cable

Listing ID #775723

Get Latest Price
  • Supply Type Manufacturer, Exporter, Supplier
  • Preferred Buyer Location All over the world

Industrial Wiring Cable is appropriate for bare copper conductor; PVC insulated Unsheathed 650/1100 V. These Industrial Wiring Cables are Single core industrial wires & cables for panel board....
View More Details
Send Enquiry

Company Information

Step Industries Private Limited verified-icon
Vishwas Nagar, Delhi
View Number
  • Member Since 10 Years
  • Nature of Business Retailer

Ask for more detail from the seller

Contact Supplier

Product Details no_img_icon

Industrial Wiring Cable is appropriate for bare copper conductor; PVC insulated Unsheathed 650/1100 V. These Industrial Wiring Cables are Single core industrial wires & cables for panel board wiring as per IS: 694 / 1990 with ISI Mark (Up to 50 sq. mm).  We are a noted Manufacturer, Exporter and Supplier of Industrial Wiring Cable in India.
Note

  • Industrial Cables above 50 sq. Mm are not covered by IS: 694 but are as per IS: 1554
  • The conductor construction given above is indicative only and will be such that all requirements.
  • Of strand diameter and conductor resistance as per IS: 694 and IS: 1554 are met.


Technical Data

  • Working voltage up to 1100 V temperature range
  • 15o C to + 70o C
  • Size 0.5 to 4.0 sq. Mm in two cores to 24 cores 6.0 to 120 dq. mm in three and four cores
  • Color Code Black and grey. White outer sheath
  • 2 core cable-red, black
  • 3 core cables-red, yellow, blue, black and grey any required colors on specific request.
  • Specification IS 6947: 1990
  • Packing in 90 Mtr. Coils, Higher sizes on drums.


Specifications

Nominal area In S.q mm No. of strands / Nom. Dia im sq. mm. Max. Of resistance ohm/km At 20 C Nominal insulation thickness (apporx.) Outer dia (approx.) Current rating in amps. Nominal area in Sq. Mm No. of strands / Nom. Dia Max. Dc Resistance dhm/ Rm at 20 C Nominal insulation thickness in mm Outer dia (approx.) Current rating in amps.
0.50 16/0.20 39.00 0.60 2.20 4 70 360/0.5 0.2772 1.6 15.5 170
0.75 24/0.20 26.00 0.60 2.50 7 95 485/0.5 0.206 1.8 18.5 210
1.00 32/0.20 19.50 0.60 2.60 11 120 608/0.5 0.161 2.0 20.9 235
1.50 48/0.20 13.30 0.60 2.90 13 150 750/0.5 0.129 2.0 225 295
2.50 80/0.20 7.95 0.70 3.50 18 185 925/0.5 0.106 2.2 24.6 330
4.00 56/0.30 4.95 0.80 4.30 24 240 1221/0.5 0.0801 2.2 27.6 400
6.00 84/0.30 3.300 0.80 5.30 33 300 1527/0.5 00641 2.4 32.2 475
10.00 140/0.30 1.910 1.00 6.70 45 400 2036/0.5 0.0486 2.6 35.7 550
16.00 126/0.4 1.210 1.00 8.20 60 500 2540/0.5 0.0384 24 38.0 625
25.00 196/0.4 0.780 1.20 10.00 75 630 3200/0.5 0.0287 3.0 45.5 725
35.00 276/0.4 0.554 1.20 11.3 95 800 4100/0.5 0.0224 3.4 51.0 850
